KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 191 -
E932- Block landing call D2 Fl.40
Blocking of door call-2 outside call - bus stop 40
E933- Block landing call D2 Fl.41
Blocking of door call-2 outside call - bus stop 41
E934- Block landingcall D2 Fl.42
Blocking of door call-2 outside call - bus stop 42
E935- Block landing call D2 Fl.43
Blocking of door call-2 outside call - bus stop 43
E936- Block landing call D2 Fl.44
Blocking of door call-2 outside call - bus stop 44
E937- Block landing call D2 Fl.45
Blocking of door call-2 outside call - bus stop 45
E938- Block landing call D2 Fl.46
Blocking of door call-2 outside call - bus stop 46
E939- Block landing call D2 Fl.47
Blocking of door call-2 outside call - bus stop 47
E940- Block landing call D2 Fl.48
Blocking of door call-2 outside call - bus stop 48
E941- Block landing call D2 Fl.49
Blocking of door call-2 outside call - bus stop 49
E942- Block landing call D2 Fl.50
Blocking of door call-2 outside call - bus stop 50
E943- Block landing call D2 Fl.51
Blocking of door call-2 outside call - bus stop 51
E944- Block landing call D2 Fl.52
Blocking of door call-2 outside call - bus stop 52
E945- Block landing call D2 Fl.53
Blocking of door call-2 outside call - bus stop 53
E946- Block landing call D2 Fl. 54
Blocking of door call-2 outside call - bus stop 54
E947- Block landing call D2 Fl. 55
Blocking of door call-2 outside call - bus stop 55
E948- Block landing call D2 Fl. 56
Blocking of door call-2 outside call - bus stop 56
E949- Block landing call D2 Fl. 57
Blocking of door call-2 outside call - bus stop 57
E950- Block landing call D2 Fl. 58
Blocking of door call-2 outside call - bus stop 58
E951- Block landing call D2 Fl. 59
Blocking of door call-2 outside call - bus stop 59
E952- Block landing call D2 Fl. 60
Blocking of door call-2 outside call - bus stop 60
E953- Block landing call D2 Fl. 61
Blocking of door call-2 outside call - bus stop 61
E954- Block landing call D2 Fl. 62
Blocking of door call-2 outside call - bus stop 62
E955- Block landing call D2 Fl. 63
Blocking of door call-2 outside call - bus stop 63
E956- Block landing call D2 Fl. 64
Blocking of door call-2 outside call - bus stop 64
E957- Monitoring Light curtain-1
Monitoring of the Light curtain Doorside-1
E958- Monitoring Light curtain-2
Monitoring of the Light curtain Doorside-2
E959- Monitoring Light curtain-3
Monitoring of the Light curtain Doorside-3
E960- Brake testing Brake 1
Inputfunction for brake-coil 1 at the TÜV-Brake test
E961- Brake testing Brake 2
Inputfunction for brake-coil 2 at the TÜV-Brake test
E962- Brake testing Brake 3
Inputfunction for brake-coil 3 at the TÜV-Brake test
E963-Controller & Light OFF
Pulse operation for shutt-off the controller & light
Monitoring UCM-relais Zone-71
Monitoring UCM-relais Zone-72
E966 Reset Travel counter
Reset function for the Travel counter
E967 Reset Direction counter Up
Reset function for the Direction counter Up
E968 Reset Direction counter Down
Reset function for the Direction counter Down
E969 Reset Direction counter
Reset function for the Direction counter
Reset function for the Line counter
E971 Reset Out Of Order Counter
Reset function for the Out Of Order Counter
E972 Reset Door Movement counter
Reset function for the Movement counter
E973 Reset Energy counter
Reset function for the Energy counter
Active if „0-level“. If active then drive to level-02. Thereafter door-up &
error message-F258
If the function is high, then there is no call above the floors
E976 Car priority with call forbidden
Like E186, but there is no car call possible
E977-Brake fan monitoring-E1
Inputs for 2nd aggregate with brake elements monitoring E1
E978-Brake fan monitoring-E2
Inputs for 2nd aggregate with brake elements monitoring E2
E979-Brake fan monitoring-E3
Inputs for 2nd aggregate with brake elements monitoring E3
If „1“ then no mistake, if „0“ then error F82 USV defect
E981 Glass breakage sensor Cabin
E982 Glass breakage sensor Shaft
E983 RWA-shaft smoke extraction
If „0“ then active => evacuation journey
E984 External call encryption OFF
By applying a control voltage of + 24V DC to an input with input function E984
"External call encryption OFF", the external call encryption can be cancelled.
E985 Hazardous goods transport
If the Fkt.=„1“, the Fkt. „Hazardous goods transport“ becomes active
E986 Door-1 emergency stop
If the Fkt.=„1“, then takes a removal of all door commands Door1
E987 Door-2 emergency stop
If the Fkt.=„1“, then takes a removal of all door commands Door2
E988 Door-3 emergency stop
If the Fkt.=„1“, then takes a removal of all door commands Door3
E989-Penthouse-9 visitors
Elevator then moves to HZ level then in Penthouse level
E990 Penthouse-9 calling Penthouse
Elevator goes to the penthouse level
E991 Penthouse-9 calling outside
Elevator moves to HZ level, then call release to penthouse level
E992-Penthouse-10 calling visitors
Elevator goes to the penthouse level then in Penthouse level
E993 Penthouse-10 calling Penthouse
Elevator goes to the penthouse level
E994 Penthouse-10 calling landing
Elevator moves to HZ level, then call release to penthouse level
Monitorinng of the railing of the car roof
E996 Evacuation Liquid Pit
If the Input is active, an evacuation travel will be done
If the Input is active, an evacuation travel will be done
