KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 169 -
A180
A180 Drive Commands V1
Expenditure of the driving command speed of V1
A181
A181 Drive Commands V2
Expenditure of the driving command speed of V2
A182
A182 Drive Commands V3
Expenditure of the driving command speed of V3
A183
A183 normal operation inverts
Expenditure of the status message normal operation inverts = out of operation
A184
A 184 Pre-end switcher Up
Expenditure of the entrance pre-end switcher UP active.
A185
A185 Pre-end switcher Down
Expenditure of the entrance pre-end switcher DOWN active.
A186
A186 Door closes
Expenditure of the message that the door closes
A187
A187 Door opens
Expenditure of the message that the door openes
A188
A188 car driving Up
Expendure of the message that the car move UP
A189
A189 car driving Down
Expendure of the message that the car move DOWN
A190
A190 trip counter impulse
Expenditure of an impulse for the trip counter
A191
A191 Drive
Expenditure of the message that the elevator is in full swing.
A192
A192 Nudging Door 1
Expenditure of the door instruction to obligation latches of the door 1
A193
A193 Nudging Door 2
Expenditure of the door instruction to obligation latches of the door 2
A194
A194 ready for use
Ready for use it means that no blockade is present.
A195
A195 Calls lie close
Car or landing calls are worked
A196
A196 Trip without Door opening
Correction or park trip is present
A197
A197 Door & Block contacts active
The safety circuit contacts Shaft-& Car Door, Block (U10,11&12) are closed
A198
A198 Safety circuit actave
The safety circuit contacts (U2 bis U9) are closed
A199
A199 landing call Up D2
Expenditure on the remote station; Acknowledgement of the external call UP
at D2
A200
A199 landing call Down Door 2
Expenditure on the remote station; Acknowledgement of the external call
DOWN at D2
A201
A201 ER Arrow Up Door 1
Expenditure of the Up-arrow on the remote station for door side 1
A202
A202 ER Arrow Down Door 1
Expenditure of the Down-arrow on the remote station for door side 1
A203
A203 ER Arrow Up Door 2
Expenditure of the Up-arror on the remote station for door side 2
A204
A203 ER Arrow Down Door 2
Expenditure of the Down-arror on the remote station for door side 2
A205
A205 light barrier blocks
Expenditure of the message that the light barrier is blocked
A206
A206 test SI light lattice
Base function to the test of the Cedes left safety light lattice
A207
A207 safety photo cell interrupt
Base function for the expenditure of a break with the cedes left safety light lat-
tice
A208
A208DSK overspeed
Base function for the overspeed ( only functional during digital shaft copying)
A209
A209 DSK V> 0,2m/s
Base function for the speed threshold V=0,2 m/s ( only functional during digital
shaft copying)
A210
A210 DSK V<Vx (m/s)
Base function for the speed threshold Vx ( only functional during digital shaft
copying)
A211
A211 elevator attendant: Tracer
Door Up
Base function for the activation of the electro magnet in the alarm tracer
A212
A212 elevator attendant: Tracer
Alarm
Base functions to the activation of the electro magnet in the door-Up-Tracer
A213
A213 elevator attendant: Control OK
Base function elevator attendant examination in order
A214
A214 elevator attendant: Monitor er-
ror
Base function elevator attendant examination incorrectly
A215
A215 Remote switcher Car
Base function for the remote release of the car
A216
A216 Reset speed limiter
Base functions for the resetting release of the car
A217
A217 Remote switcher Counterbal-
ance
Base functions for the release of the remote release of the counterweight
A218
A218 Reset speed limiter counter-
balance
Base functions for the reserting release of the remote release of the counter-
weight
A219
A219 Car-Call-M.Door.1 St.01
Base function acknowledgement car call door side 1 Stop 1
A220
A220 Car-Call-M.Door.1 St.02
Base function acknowledgement car call door side 1 Stop 2
A221
A221 Car-Call-M.Door.1 St.03
Base function acknowledgement car call door side 1 Stop 3
A222
A222 Car-Call-M.Door.1 St.04
Base function acknowledgement car call door side 1 Stop 4
A223
A223 Car-Call-M.Door.1 St.05
Base function acknowledgement car call door side 1 Stop 5
A224
A224 Car-Call-M.Door.1 St.06
Base function acknowledgement car call door side 1 Stop 6
A225
A225 Car-Call-M.Door.1 St.07
Base function acknowledgement car call door side 1 Stop 7
A226
A226 Car-Call-M.Door.1 St.08
Base function acknowledgement car call door side 1 Stop 8
A227
A227 Car-Call-M.Door.1 St.09
Base function acknowledgement car call door side 1 Stop 9
A228
A228 Car-Call-M.Door.1 St.10
Base function acknowledgement car call door side 1 Stop 10
A229
A229 Car-Call-M.Door.1 St.11
Base function acknowledgement car call door side 1 Stop 11
A230
A230 Car-Call-M.Door.1 St.12
Base function acknowledgement car call door side 1 Stop 12
A231
A231 Car-Call-M.Door.1 St.13
Base function acknowledgement car call door side 1 Stop 13
A232
A232 Car-Call-M.Door.1 St.14
Base function acknowledgement car call door side 1 Stop 14
A233
A233 Car-Call-M.Door.1 St.15
Base function acknowledgement car call door side 1 Stop 15
A234
A234 Car-Call-M.Door.1 St.16
Base function acknowledgement car call door side 1 Stop 16
A235
A235 Car-Call-M.Door.1 St.17
Base function acknowledgement car call door side 1 Stop 17
A236
A236 Car-Call-M.Door.1 St.18
Base function acknowledgement car call door side 1 Stop 18
A237
A237 Car-Call-M.Door.1 St.19
Base function acknowledgement car call door side 1 Stop 19
