KW DAVID 613 - Page 171

KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 171 -
A304
A301 Trafic light outside E02 D2
Green= if the door open + Car empty
A305
A301 Trafic light outside E03 D1
Green= if the door open + Car empty
A306
A301 Trafic light outside E03 D2
Green= if the door open + Car empty
A307
A301 Trafic light outside E04 D1
Green= if the door open + Car empty
A308
A301 Trafic light outside E04 D2
Green= if the door open + Car empty
A309
☺A309 Door 1 closes IMPULS
voice output
A310
☺A310 Door 1 opens IMPULS
voice output
A311
☺A311 Door 2 closes IMPULS
voice output
A312
☺A312 Door 2 opens IMPULS
voice output
A313
A313 Bolt move
To control the contactor of the hydraulic motor
A314
A314 bolt drive out
Feedback
A315
A315 Bolt drive in
Feedback
A316
A316 Timer-1
Time switch clock with 2 thresholds
A317
A317 Timer-2
Time switch clock with 2 thresholds
A318
A318 Timer-3
Time switch clock with 2 thresholds
A319
A319 Timer-4
Time switch clock with 2 thresholds
A320
A320 Timer-5
Time switch clock with 2 thresholds
A321
A321 Timer-6
Time switch clock with 2 thresholds
A322
A322 Timer-7
Time switch clock with 2 thresholds
A323
A323 Timer-8
Time switch clock with 2 thresholds
A324
A324 Timer-9
Time switch clock with 2 thresholds
A325
A325 Timer-10
Time switch clock with 2 thresholds
A326
A326 Catch rescue
A327
A327 Car Indication 1 of N
Floor 13
A328
A328 Car Indication 1 of N
Floor 14
A329
A329 Car Indication 1 of N
Floor 15
A330
A330 Car Indication 1 of N
Floor 16
A331
A331 Car Indication 1 of N
Floor 17
A332
A332 Car Indication 1 of N
Floor 18
A333
A333 Car Indication 1 of N
Floor 19
A334
A334 Car Indication 1 of N
Floor 20
A335
A335 Car Indication 1 of N
Floor 21
A336
A336 Car Indication 1 of N
Floor 22
A337
A337 Car Indication 1 of N
Floor 23
A338
A338 Car Indication 1 of N
Floor 24
A339
A339 Car Indication 1 of N
Floor 25
A340
A340 Car Indication 1 of N
Floor 26
A341
A341 Car Indication 1 of N
Floor 27
A342
A342 Car Indication 1 of N
Floor 28
A343
A343 Car Indication 1 of N
Floor 29
A344
A344 Car Indication 1 of N
Floor 30
A345
A345 Car Indication 1 of N
Floor 31
A346
A346 Car Indication 1 of N
Floor 32
A347
A347 Watchdog timing
Expenditure of the message in the case of active error watching timing
A348
A348 Emergency Stop U9
Expenditure of the message in the case of active emergency stop.
A349
A349 NBS
Drive signale to control the NBS-TSBrake with 1 Sec. delaytime
A350
A350 Door Open Button
Expenditure of the active door up tracer during the door play.
A351
A351 2 Seconds pulse Codekey
A352
A352 Door-Closed and Drive
A353
A353 Hydr.Insp.-Down
Inspection-Down at ALGI AZFR
A354
A354 Missbrauch aktiv
Back-message abuse protection active
A355
A355 Car Elevator D1 AHEAD
Indicator Ahead Doorside 1
A356
A356 Car Elevator D1 STOP
Indicator Stop Doorside 1
A357
A357 Car Elevator D1 RETURN
Indicator Return Doorside 1
A358
A358 Car Elevator D2 AHEAD
Indicator Ahead Doorside 2
A359
A359 Car Elevator D2 STOP
Indicator Stop Doorside 2
A360
A360 Car Elevator D1 RETURN
Indicator Return Doorside 2
A361
A361 Sink Avoiding
Speedlimiter on the car, Always “1”“, without testing
A362
A362 Controler Cabinet
Controller cabin Light E459, E460
A363
A363 Traffic Light F05 Door-1
Green=1, if the door is open and the car is empty
A364
A364 Traffic Light F05 Door-2
Green=1, if the door is open and the car is empty
A365
A365 Traffic Light F06 Door-1
Green=1, if the door is open and the car is empty
A366
A366 Traffic Light F06 Door-2
Green=1, if the door is open and the car is empty
A367
A367 Traffic Light F07 Door-1
Green=1, if the door is open and the car is empty
A368
A368 Traffic Light F07 Door-2
Green=1, if the door is open and the car is empty
A369
A369 Traffic Light F08 Door-1
Cabin Door closed (U10+U11), Green=1, if the door is open and the car is
empty
A370
A370 Traffic Light F08 Door-2
Green=1, if the door is open and the car is empty
