KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 173 -
A436
A436 A.F.cl-D2 UP Floor 18
Attendant Function: Visualisation Landing Call UP Door-2 Floor 18
A437
A437 A.F.cl-D2 UP Floor 19
Attendant Function: Visualisation Landing Call UP Door-2 Floor 19
A438
A438 A.F.cl-D2 UP Floor 20
Attendant Function: Visualisation Landing Call UP Door-2 Floor 20
A439
A439 A.F.cl-D2 UP Floor 21
Attendant Function: Visualisation Landing Call UP Door-2 Floor 21
A440
A440 A.F.cl-D2 UP Floor 22
Attendant Function: Visualisation Landing Call UP Door-2 Floor 22
A441
A441 A.F.cl-D2 UP Floor 23
Attendant Function: Visualisation Landing Call UP Door-2 Floor 23
A442
A442 A.F.cl-D2 UP Floor 24
Attendant Function: Visualisation Landing Call UP Door-2 Floor 24
A443
A443 A.F.cl-D2 UP Floor 25
Attendant Function: Visualisation Landing Call UP Door-2 Floor 25
A444
A444 A.F.cl-D2 UP Floor 26
Attendant Function: Visualisation Landing Call UP Door-2 Floor 26
A445
A445 A.F.cl-D2 UP Floor 27
Attendant Function: Visualisation Landing Call UP Door-2 Floor 27
A446
A446 A.F.cl-D2 UP Floor 28
Attendant Function: Visualisation Landing Call UP Door-2 Floor 28
A447
A447 A.F.cl-D2 UP Floor 29
Attendant Function: Visualisation Landing Call UP Door-2 Floor 29
A448
A448 A.F.cl-D2 UP Floor 30
Attendant Function: Visualisation Landing Call UP Door-2 Floor 30
A449
A449 A.F.cl-D2 UP Floor 31
Attendant Function: Visualisation Landing Call UP Door-2 Floor 31
A450
A450 A.F.cl-D2 DOWN Floor 17
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 17
A451
A451 A.F.cl-D2 DOWN Floor 18
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 18
A452
A452 A.F.cl-D2 DOWN Floor 19
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 19
A453
A453 A.F.cl-D2 DOWN Floor 20
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 20
A454
A454 A.F.cl-D2 DOWN Floor 21
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 21
A455
A455 A.F.cl-D2 DOWN Floor 22
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 22
A456
A456 A.F.cl-D2 DOWN Floor 23
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 23
A457
A457 A.F.cl-D2 DOWN Floor 24
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 24
A458
A458 A.F.cl-D2 DOWN Floor 25
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 25
A459
A459 A.F.cl-D2 DOWN Floor 26
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 26
A460
A460 A.F.cl-D2 DOWN Floor 27
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 27
A461
A461 A.F.cl-D2 DOWN Floor 28
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 28
A462
A462 A.F.cl-D2 DOWN Floor 29
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 29
A463
A463 A.F.cl-D2 DOWN Floor 30
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 30
A464
A464 A.F.cl-D2 DOWN Floor 31
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 31
A465
A4653 A.F.cl-D2 DOWN Floor 32
Attendant Function: Visualisation Landing Call DOWN Door-2 Floor 32
A466
A466 Traffic Light Flash
Function for Car-Elevators
A467
A467 A3-Case Active
If you have an A3-Case ( Error F60 ) it is active
A468
A468 Piezo Buzzer
Active at FirefighterFunction or Inspection or Door blocking after 2 minutes
A469
A469 OSCAR activ
If Level = „1“, than active
A470
A470 Brake Open
If Level = „1“, than brake open ( Depends on E25 invert.).
A471
A471 Error Shaft-Door-Heating
Error Shaft-Door Floor-Heating
A472
A472 Impuls Main-Hour-Counter
Impulse lenght 1 Sec.
A473
A473 Impuls Operation-Counter
Impulse lenght 1 Sec
A474
A474 Impuls Door-Counter-1
Impulse lenght 1 Sec
A475
A475 Impuls Door-Counter-2
Impulse lenght 1 Sec
A476
A476 Error Car-Fan-Monitoring
A477
A477 Error Car-Light-Monitoring
A478
A478 Error Endswitch Top
A479
A479 Error Endswitch Bottom
A480
A480 Error Leveling
A481
A481 Error Electric Socket
A482
A482 Stand-by
If Level = „1“, than Stand-by-Operation (Message)
A483
A483 Maintenance
If Level = „1“, than E258 active (Message)
A484
A484 Calmed Operation
If Level = „1“, than Calm traffic (Message)
A485
A485 A.C.cl-D1 Floor 33
Visualisation of the Car call – Door-1
A486
A486 A.C.cl-D1 Floor 34
Visualisation of the Car call – Door-1
A487
A487 A.C.cl-D1 Floor 35
Visualisation of the Car call – Door-1
A488
A488 A.C.cl-D1 Floor 36
Visualisation of the Car call – Door-1
A489
A489 A.C.cl-D1 Floor 37
Visualisation of the Car call – Door-1
A490
A490 A.C.cl-D1 Floor 38
Visualisation of the Car call – Door-1
A491
A491 A.C.cl-D1 Floor 39
Visualisation of the Car call – Door-1
A492
A492 A.C.cl-D1 Floor 40
Visualisation of the Car call – Door-1
A493
A493 A.C.cl-D1 Floor 41
Visualisation of the Car call – Door-1
A494
A494 A.C.cl-D1 Floor 42
Visualisation of the Car call – Door-1
A495
A495 A.C.cl-D1 Floor 43
Visualisation of the Car call – Door-1
A496
A496 A.C.cl-D1 Floor 44
Visualisation of the Car call – Door-1
A497
A497 A.C.cl-D1 Floor 45
Visualisation of the Car call – Door-1
A498
A498 A.C.cl-D1 Floor 46
Visualisation of the Car call – Door-1
A499
A499 A.C.cl-D1 Floor 47
Visualisation of the Car call – Door-1
A500
A500 A.C.cl-D1 Floor 48
Visualisation of the Car call – Door-1
A501
A501 A.C.cl-D1 Floor 49
Visualisation of the Car call – Door-1
A502
A502 A.C.cl-D1 Floor 50
Visualisation of the Car call – Door-1
A503
A503 A.C.cl-D1 Floor 51
Visualisation of the Car call – Door-1
