B72 Allocation Inputs
The Inputs ZR-, ZG-, FKR-, and ITR-unit can be occupied in principle with the functions speci-
fied down.
No function is assigned to the entrance.
E01- EMERGENCY POWER OPERATION
Entrance for the message of the emergency power operation
E02- EMERGENCY POWER DRIVE
Entrance for the beginning of the emergency power trip
Entrance for the barrier of the restart
Entrance for the restarting operation of the system
Entrance for the disconnection of the cab light
Entrance for the automatic controller message release
Entrance for the automatic controller message stop
E08-Disturbance regulation
Entrance for the automatic controller message distrubance.
Entrance for the message of the protection circuit - the zone is active
Entrance for the message of the protection circuit over your status
Entrance for the overload message
Entrance for the full load message
Entrance for the less message
Entrance for the contactor feedback
E15- External control off
Entrance for switching the external control off
E16-/control & Light off/
Entrance for switching the control and the cab light off
E17-Fire brigade outside 1 Priorität
Entrance for the FW lock for landing call 1th floor
E18-Fire brigade outside 2 Priorität
Entrance for the FW lock for landing call 2nd floor
E19-Fire brigade outside 3 Priorität
Entrance for the FW lock for landing call 3rd floor
Entrance for the FW lock in the cab
E21-Fire-brigade instruction
Entrance for the KW control after Australian model
Entrance for the ramp trip
Entrance for the switch for the leader enterprise
Entrance for the tracer for the activation of the cab exhaust
E25- Brake ventilating monitoring
Entrance for the brake ventilation monitoring opening & Latches brake
E26-Brake wear monitoring
Entrance for the monitoring of the brake lining
E27-maintenance doors close
Entrance for the activation of the catch of the doors for 15 minutes
Entrance for the call of the lowest floor
Entrance for the call of the highest floor
Entrance for teh rescue trip
Entrance of the lobby monitor of the door 1
Entrance of the lobby monitor of the door 2
Entrance for the tracer door 1 open
Entrance for the tracer door 1 close
Entrance for the tracer door 2 open
Entrance for the tracer door 2 close
E37-Load time tracer door 1
Entrance for the load time tracer door 1
E38Load time tracer door 2
Entrance for the load time tracer door 2
Entrance for extracting an elevator from the groop > own landing calls
E40- Fire drop level Prioritat 1
Entrance for the fire drop evaclation into the first evacuation level
E41- Fire drop level Prioritat 2
Entrance for the fire drop evaclation into the second evacuation level
E42- Fire drop level Prioritat 3
Entrance for the fire drop evaclation into the third evacuation level
Entrance for floor fire alarms of the Stop 01
Entrance for floor fire alarms of the Stop 02
Entrance for floor fire alarms of the Stop 03
Entrance for floor fire alarms of the Stop 04
Entrance for floor fire alarms of the Stop 05
Entrance for floor fire alarms of the Stop 06
Entrance for floor fire alarms of the Stop 07
Entrance for floor fire alarms of the Stop 08
Entrance for floor fire alarms of the Stop 09
Entrance for floor fire alarms of the Stop 10
Entrance for floor fire alarms of the Stop 11
Entrance for floor fire alarms of the Stop 12
Entrance for floor fire alarms of the Stop 13
Entrance for floor fire alarms of the Stop 14
Entrance for floor fire alarms of the Stop 15
Entrance for floor fire alarms of the Stop 16
Entrance for floor fire alarms of the Stop 17
Entrance for floor fire alarms of the Stop 18
