KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 180 -
E197 - Landing Priority D.2 St.10
Entrance landing priority the selective door 2 in the stop 10
E198 - Landing Priority D.2 St.11
Entrance landing priority the selective door 2 in the stop 11
E199 - Landing Priority D.2 St.12
Entrance landing priority the selective door 2 in the stop 12
E200 - Landing Priority D.2 St.13
Entrance landing priority the selective door 2 in the stop 13
E201 - Landing Priority D.2 St.14
Entrance landing priority the selective door 2 in the stop 14
E202 - Landing Priority D.2 St.15
Entrance landing priority the selective door 2 in the stop 15
E203 - Landing Priority D.2 St.16
Entrance landing priority the selective door 2 in the stop 16
E204 - Landing Call D.2 Open St.01
Entrance car call up at the selective door 2 in the stop 01
E205 - Landing Call D.2 Open St.02
Entrance car call up at the selective door 2 in the stop 02
E206 - Landing Call D.2 Open St.03
Entrance car call up at the selective door 2 in the stop 03
E207 - Landing Call D.2 Open St.04
Entrance car call up at the selective door 2 in the stop 04
E208 - Landing Call D.2 Open St.05
Entrance car call up at the selective door 2 in the stop 05
E209 - Landing Call D.2 Open St.06
Entrance car call up at the selective door 2 in the stop 06
E210 - Landing Call D.2 Open St.07
Entrance car call up at the selective door 2 in the stop 07
E211 - Landing Call D.2 Open St.08
Entrance car call up at the selective door 2 in the stop 08
E212 - Landing Call D.2 Open St.09
Entrance car call up at the selective door 2 in the stop 09
E213 - Landing Call D.2 Open St.10
Entrance car call up at the selective door 2 in the stop 10
E214 - Landing Call D.2 Open St.11
Entrance car call up at the selective door 2 in the stop 11
E215 - Landing Call D.2 Open St.12
Entrance car call up at the selective door 2 in the stop 12
E216 - Landing Call D.2 Open St.13
Entrance car call up at the selective door 2 in the stop 13
E217 - Landing Call D.2 Open St.14
Entrance car call up at the selective door 2 in the stop 14
E218 - Landing Call D.2 Open St.15
Entrance car call up at the selective door 2 in the stop 15
E219 - Landing Call D.2 Open St.01
Entrance landing call down at the selective door 2 in the stop 01
E220 - Landing Call D.2 Open St.02
Entrance landing call down at the selective door 2 in the stop 02
E221 - Landing Call D.2 Open St.03
Entrance landing call down at the selective door 2 in the stop 03
E222 - Landing Call D.2 Open St.04
Entrance landing call down at the selective door 2 in the stop 04
E223 - Landing Call D.2 Open St.05
Entrance landing call down at the selective door 2 in the stop 05
E224 - Landing Call D.2 Open St.06
Entrance landing call down at the selective door 2 in the stop 06
E225 - Landing Call D.2 Open St.07
Entrance landing call down at the selective door 2 in the stop 07
E226 - Landing Call D.2 Open St.08
Entrance landing call down at the selective door 2 in the stop 08
E227 - Landing Call D.2 Open St.09
Entrance landing call down at the selective door 2 in the stop 09
E228 - Landing Call D.2 Open St.10
Entrance landing call down at the selective door 2 in the stop 10
E229 - Landing Call D.2 Open St.11
Entrance landing call down at the selective door 2 in the stop 11
E230 - Landing Call D.2 Open St.12
Entrance landing call down at the selective door 2 in the stop 12
E231 - Landing Call D.2 Open St.13
Entrance landing call down at the selective door 2 in the stop 13
E232 - Landing Call D.2 Open St.14
Entrance landing call down at the selective door 2 in the stop 14
E233 - Landing Call D.2 Open St.15
Entrance landing call down at the selective door 2 in the stop 15
E234 - Landing Call D.2 Open St.16
Entrance landing call down at the selective door 2 in the stop 16
Entrance of the universal channel 1
Entrance of the universal channel 2
Entrance of the universal channel 3
Entrance of the universal channel 4
E239 Entrance delay relay 1
Activation entrance the time delay relay1
E239 Entrance delay relay 2
Activation entrance the time delay relay1
E241-Obligation Delay V1 up
Opener contact interrupted, speed of V1 up taken away
E242-Obligation Delay V1 up
Opener contact interrupted, speed of V2 up taken away
E243-Obligation Delay V1 up
Opener contact interrupted, speed of V3 up taken away
E244-Obligation Delay V1 down
Opener contact interrupted, speed of V4 down taken away
E245-Obligation Delay V1 down
Opener contact interrupted, speed of V5 down taken away
E246-Obligation Delay V1 down
Opener contact interrupted, speed of V6 down taken away
If the opener-contact is interrupted, Stop at the next floor
E248-ER landing call up D2
Input function at the remote station; Landing call Up Door 2
E249-ER landing call down D2
Input function at the remote station; Landing call Down Door 2
Input function at the remote station ER: Priority call at doorside 1
Input function at the remote station ER: Priority call at doorside 2
E252 Blockade Door side 1
In the case of activation of the entrance-> Door side 1 not opened. (
fire drop gate)
E253 Blockade Door side 2
In the case of activation of the entrance-> Door side 2 not opened. (
fire drop gate)
E254 Reset Safety Photo Cell
Input function for the Reset-button for CEDES LI-Safety photocell
E255 Monitor Safety Photo Cell
Input function for the contactor monitor for CEDES LI-Safety photocell
If there is a high level (+24V) the input channel is activated. If there is
no input channel, the output beginns after 7 seconds.
AW emergency call function
Input function for the activation of the alarm horn
Output messages will be deleted
If the swing apron is closed, the level is „1“
E260 Button Remote Switcher
If „1“ and appropriate inspector function actively then appropriate exit
actively.
