KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 203 -
F65
Push-Button landing call up
Tracer landing call up wedges
F66
Push-Button landing call down
Tracer landing call down wedges
F67
Push-Button Door open
An entry takes place if the tracer is operated longer than 45
seconds in the stop and/ or in normal operation.
F68
Photocell blocked
An entry takes place if the lght barrier is operated longer than
45 seconds in the stop and/ or in normal operation.
F69
Revers Contact blocked
An entry takes place if the contact is operated longer than 45
secods in the stop and/or in normal operation
F70
Blocked – End switch
The hydraulic elevator is driven into the top end-switch. After
leaving the top-end-switch the elevator has lowered and
blocked in the lowest stop.
F71
Blocked Journey time
The hydraulic elevator lowered after the occurance of a run
time arror
F72
Blocked- TV60-1
Two inputs channels of the TV60-1 are monitored for synchro-
nization.
F73
Blocked- TV60-2
Two inputs channels of the TV60-2 are monitored for synchro-
nization.
F78
DSC 2. Pre-switch Bottom
The digital shaft copying have started that the counted im-
pulse conditions do not agree with the impulse conditions at
the pre-end switcher down. A correction was implemented.
F79
DSC 2. Pre-switch Top
The digital shaft copying have started that the counted im-
pulse conditions do not agree with the impulse conditions at
the pre-end switcher up. A correction was implemented.
F80
Communication I/O CPU
The central unit and logic unit is internally disturbed. Ask cus-
tomer service- reasonable.
F81
Communication I/O FKR
Communication to the car controller is disturbed. That is 15
pole. D-Subkabel correctly put or damages?
F82
USV Defect / empty
The UPS for emergency rescue is defective, or the charge
status is empty.
F83
DSC Change Puls
The encoder pulses of the shaft encoder must be exchanged.
( Input 81 and 82)
F84
DSC No pulses
From the pulse generator of the digital pit copying no impulses
come. Are the giver and impulse entry correct?
F85
DSC Floornumber
The floor number determined by the learning trip does not
agree with the registered. Please examine the entry in the
software and zone switch for switching gap and function.
F86
Correction ZONE
Correction trip released by counter deviation for the zone.
F87
Correction Pre-Switch Down
Correction trip released by counter deviation
Pre-end-switch down
F88
Correction Pre-Switch Top
There is a difference between the counter of the digital shaft-
copy and the position of the Pre-switch top. The counter was
adapted.
F90
Watchdog-Reset
Internal reset – damage in the hardware
F91
Reset-Groupbus
Internal reset due to error in the group bus
F92
Security circuit
The security circuit has sent an error. A cause a missing or re-
tarded zone.
F93
Liftbus Communication
On the Liftbus (communication regulation STG) an error was
sent.
F94
Test Safety Photocell
An error was announced of the safety photocell which was de-
termined by the self check.
F95
Interrupt Safety Photocell
An error was announced of the safety photocell which was de-
termined during the travel.
F97
Zone Switches
The contacts of the zone switches have a lot of switching acts
F98
Prelevel-Switch-UP
The contact of the Prelevel-switch UP has a lot of switching
acts.
F99
Prelevel-Switch-DOWN
The contact of the Prelevel-switch Down has a lot of switching
acts
