- Is there really SSI-encoder connected? -> Menu A4 Motor/Gearbox -> Encoder system
- The encoder is out of order, e.g. after the test of the safety gear?
- The encoder is falsely connected -> Please check the pinning -> Did you use the right adapter?
- The encoder wire is out of order or too long ( >30m) ! -> Please increase the encoder voltage!
- The encoder wire is parallel to the motor wire -> Change it immediately!
- The encoder coupling or the encoder is not mechanically fixed with the motor wave -> Please check
- Is there really EnDat-encoder connected? -> Menu A4 Motor/Gearbox -> Encoder system
- The encoder is out of order, e.g. after the test of the safety gear?
- The encoder is falsely connected -> Please check the pining -> Did you use the right adapter?
- The encoder wire is out of order or too long ( >30m) ! -> Please increase the encoder voltage!
- The encode rwire is parallel to the motorwire -> Change it immediately!
The encoder coupling or the encoder is not mechanically fixed with the motor wave -> Please check it!
- Is there really Hiperface-encoder connected? ->Menu A4 Motor/Gearbox-> Encoder sys-
tem
- The encoder is out of order, e.g. after the test of the safety gear?
- The encoder is falsely connected -> Please check the pinning -> Did you use the right adapter?
- The encoder wire is out of order or too long ( >30m) ! -> Please increase the encoder voltage!
- The encoder wire is parallel to the motor wire -> Change it immediatly!
- The encoder coupling or the encoder is not mechanically fixed with the motor wave -> Please check
- Is there really Sin/Cos-encoder connected? -> Menu A4 Motor/Gearbox -> Encodersystem
- The encoder is out of order, e.g. after the test of the safety gear?
- The encoder is falsely connected -> Please check the pinning -> Did you use the right adapter?
- The encoder wire is out of order or too long ( >30m) ! -> Please increase the encoder voltage!
- The encoder wire is parallel to the motor wire -> Change it immediatly!
- The encoder coupling or the encoder is not mechanically fixed with the motor wave -> Please check
- The number of pulses are wrong -> Please change the setting
- The encoder channels are out of order -> Please change the encoder?
- The encoder is falsely connected -> Please check the pinning -> Did you use the right adapter?
- Short cut at the encoder terminal -> Please check the pinning -> Did you use the right adapter?
- The encoder is out of order, e.g. after the test of the safety gear?
- The encoder is falsely connected -> Please check the pinning -> Did you use the right adapter?
- The encoderwire is out of order or too long ( >30m) ! -> Please increase the encoder voltage!
- Is the correct type of encoder connected? -> Menu A4 Motor/Gearbox -> Encoder system
Motor Temperature-too high:
- The temperature of the area is too high
- The motor is overloaded
- The motor fan is out of order
Command Voltage-too low: Short cut at the 24V-Terminal, 24V-Terminal is overloaded:
- Short cut at the output terminal +24V -> Please check as soon as possible !
- The output channel +24V is overloaded -> please use an external power supply !
- Short cut at the output terminal -> Please check the pinning
The output channels EA1 to EA8 are overloaded -> Perhaps there is a short cut or the current is too
high -> Please check it, perhaps you must use external relays!
Internal Relay-1 is out of order or the open-contact is clewing -> The switching load is too big (Induc-
tive)! Please use a contactor to switch big loads, like the brake-magnet!
Internal Relay-2 is out of order or the open-contact is clewing -> The switching load is too big (Induc-
tive)! Please use a contactor to switch big loads, like the brake-magnet!
Internal Relay-3 is out of order or the open-contact is clewing -> The switching load is too big (Induc-
tive)! Please use a contactor to switch big loads, like the brake-magnet!
