KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 24 -
When the button is
pressed, the doors
remain closed for 15
minutes. 2.th Press -
> open doors
-> Elevator car
moves to the top
stop.
-> Elevator car
drives to the lowest
stop.
Upper side panel: (left to right)
2x input & output terminals (8 free I / O)
ZD0.7, Zone, Alarm & Motor PTC, Bus
display RJ12 push
button call Lowermost
stop, Call top call button, Maintenance
button Doors closed For 15 minutes, Con-
nection Maintenance indicator / HPG-
RJ12
1x input & output terminals (8 free I / O)
ZE0.7
Left sidewall: (from left to right)
Upper level:
3x group bus, 1x absolute encoder con-
nection, 2x CANOpen bus, 2 USB masters
Middle level:
1x Chassis bus RJ45, 1x Liftbus RJ45, 1x
incremental connection, 1x USB slave, 2x
serial interfaces, 6 freely assignable relay
outputs (K301 to K306)
Lower level:
Power connections for phase processor
& emergency power (N, L6, L5, PE).
Right sidewall: (from left to right)
24
freely assignable inputs and outputs
ZA0.7, ZB0.7, ZC0.7,
2x 230V AC inputs for emergency evacu-
ation and cabin lighting
Connection inspection contactor K60,
2xintercom, 5 free hanging cable veins
Lower part of the page: (left to right)
3x outputs for
contactor monitoring of the
positively driven control relays
12x 230V-AC inputs for safety circuit inter-
rogation (U1 to U12),
H01- Terminal -Description Main Controller Rope
