KW Aufzugstechnik GmbH OPERATING MANUAL DAVID-613
DAVID-D613-V125-E 13.04.2021 Page - 97 -
Parameter : Command Output
In this parameter it can be selected between Standard NGV-A3 attitude and Oildynamic
NGV-A3 attitude. If Oildynamic is selected then pilot control will be printed only if input E494
is on.
Attention! Also set the Bucher iValve setting for the regulated BLAIN block SEV!
In the case of the Bucher-iValve setting, all commands with a high level + 24V are output
(-> note the setting on the iCon!):
Pin
Bucher
iCon
BUCHER iValve Function
DAVID D613 output function
PIN-
D613
(Default)
X7.6
Command K1 Fast UP
A181 UP Fast
ZE 2
X7.5
Command K2 Slowly UP
A176 Down Slowly, UP catch up
ZE 0
X7.4
Command K3 Fast Down
A182 Down Fast
ZE 4
X7.3
Command K4 Slowly Down
A175 Down Slowly, Down catch up
ZE 1
X7.2
Command K5 Inspection
A177 Inspection
ZE 5
X6.4
Command K6 intermediate speed
A180 Intermediate speed
ZE 3
X7.2
0V GND mass
0V GND mass
500
The following output messages of the Bucher iCon are reported to the D613 (all messages with high
level + 24V):
Pin Bucher
iCon
BUCHER iValve Function
DAVID D613 input function
PIN-
D613
(Default)
X2.1
Relais Error SIU
E008 Controller fault
ZC 3
X2.2
Relais Error SIU
Control voltage +24V DC
200
X2.5
Relais s1 Overload
E011 Overload
ZB 2
X2.6
Relais s1 Overload
Control voltage +24V DC
200
X2.8
Relais s2 Reduced pressure
E434 Reduced pressure
ZE 7
X2.7
Relais s2 Reduced pressure
Control voltage +24V DC
200
The following output messages of the Bucher iCon are reported to the D613 (all messages with high
level + 24V):
Pin Bucher
iCon
BUCHER iValve Function
DAVID D613 input function
PIN-
D613
(Default)
X10 +SMA
Monitoring emergency stop Down
UCM
E495 UCM Status
ZE 6
X10 GND
0V GND mass
0V GND mass
500
Parameter Feedforward K32 delayed OFF
The SAG-90 is switched off with a delay. The possible time range is 10 to 3000 ms.
Parameter Commando Vi(A177) inverted
For normal electronic ALGI RZRS 2.0 it is necessary to invert the commando Vi.
