2M4/2M5/2M6/2M7
2-3-9
Connector Pin Signal I/O Voltage Description
YC5 1 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB
Connected to
APC PWB
2 LONBN O 0/3.3 V DC Sample/hold signal
3 LDCONT O 0/3.3 V DC LD voltage control signal
4 PDN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
5 GND - - Ground
6 LDENBN O 0/3.3 V DC Laser output enable signal
7 VIDEO O 0/3.3 V DC (pulse) Video data signal (-)
8 VIDEON O 0/3.3 V DC (pulse) Video data signal (+)
YC8 1 VOUT I Analog Data signal
Connected to
CIS
2 MODE O 0/3.3 V DC Mode signal
3AGND - - Ground
4 +3.3VCIS O 3.3 V DC 3.3 V DC power to CIS
5 CISVREF O 1.1 V DC 1.1 V DC power output to VREF
6 SP O 0/3.3 V DC (pulse) Vertical transfer pulse
7 CLK O 0/3.3 V DC (pulse) Clock signal
8 LEDANODE O 18 V DC
9 LEDB I 0/6 V DC LED control signal
10 LEDG I 0/6 V DC LED control signal
11 LEDR I 0/6 V DC LED control signal
12 AGND - - Ground
YC12 1 GND - - Ground
Connected to
Power
source PWB
2 GND - - Ground
3 +24V1 I 24V DC 24 V DC power from PSPWB
4 PUSHSW I 0/3.3 V DC power SW signal
5 HEATREM O 0/3.3 V DC Heater On/Off signal
6 RELAY O DC0V/24V Relay signal
7 PSSLEEPN O DC0V/24V Sleep mode signal
8 ZCROSS O 0/3.3 V DC (pulse) Zero-cross signal
9 +24V2 I 24V DC 24 V DC power from PSPWB
10 +24V2 I 24V DC 24 V DC power from PSPWB
YC13 1 GND - - Ground
Connected to
high voltage
PWB
2 MISENS I 0/3.3 V DC Charge current signal
3 TCNT O PWM Transfer current signal
4 MCNT O PWM Main charger output control signal
5 RTHVDR O 0/3.3 V DC Transfer (reverse) bias output signal
6 HVCLK O 0/3.3 V DC (pulse) Developer bias clock signal
7 +24V3 O 24V DC 24 V DC power to PSPWB
To Next Page
