Kyocera ECOSYS FS-1020MFP - Page 188

2M4/2M5/2M6/2M7
2-3-10
YC14 1 THERM I Analog TH detection signal
Connected to
relay PWB
2 GND - - Ground
3 SECDATA I 0/3.3 V DC CS data signal
4 SECCLK O 0/3.3 V DC (pulse) CS clock signal
5 +3.3V3 O 3.3 V DC 3.3 V DC power to RPWB
6 TONERSENS I 0/3.3 V DC Toner presence signal
7 REGIST I 0/3.3 V DC RS: On/Off
8 PULSE I 0/3.3 V DC (pulse) Encorder plus signal
9 GND - - Ground
10 MOTCLK O 0/24 V DC (pulse) MM clock signal
11 FANDRN O DC0V/24V FM: On/Off
12 FEEDSOLDRN O DC0V/24V PFSOL: On/Off
13 DUSOLDRN O DC0V/24V DUSOL: On/Off
14 +24V3 O 24V DC 24 V DC power to RPWB
15 +24V3 O 24V DC 24 V DC power to RPWB
YC15 1 +3.3V3 O 3.3 V DC 3.3 V DC power to FTH
Connected to
fuser therm-
istor
2 FTHERM I Analog Fuser thermistor detection signal
YC17 1 +24V3 O 24V DC 24 V DC power to PM
Connected to
polygon
motor
2 GND - - Ground
3 POLONN O 0/3.3 V DC PM: On/Off
4 POLORDYN I 0/3.3 V DC Polygon motor ready signal
5 POLCLK O 0/3.3 V DC (pulse) Polygon motor clock signal
YC18 1 SCMOTB1 O 0/24 V DC (pulse) Scanner motor control signal
Connected to
scanner
motor
2 SCMOTB2 O 0/24 V DC (pulse) Scanner motor control signal
3 SCMOTA1 O 0/24 V DC (pulse) Scanner motor control signal
4 SCMOTA2 O 0/24 V DC (pulse) Scanner motor control signal
YC20 1 +24VERASER O 24V DC 24 V DC power to CL
Connected to
Eraser lamp
2 ERASER O 0/3.3 V DC CL: On/Off
Connector Pin Signal I/O Voltage Description
