2M4/2M5/2M6/2M7
1-2-5
3 in 1 20/21 ppm model
Figure 1-2-5
*: Place the machine on a level surface.
4
2
1
8
9
3
6
11
13
15
12
14
7
16
10
5
1. Machine
2. Outer case
3. Bottom left pad
4. Bottom right pad
5. Machine cover
6. Top left pad
7. Top right pad
8. Top spacer
9. Operation panel sheets
10. Spacer
11. Cassette cover
12. Toner container
13. CDROM
14. Quick installation guide etc.
15. Power cord
16. USB cable*
*:China model only
