2M4/2M5/2M6/2M7-1

1-2-6

3 in 1 25/26 ppm model,4 in 1 20/21,25/26 ppm model

1. Remove seven tapes.

Figure 1-2-6

2. Remove tape.

Figure 1-2-7

Removing the tapes

Tapes

Tape

Tape

Tape
