Kyocera FS-C8500DN Service Manual

2KA
1-3-65
U234
Setting punch destination
Description
Sets the destination of punch unit of 3000-sheet document finisher.
Purpose
To be set when installing a different punch unit from the destination of the machine.
Setting
1. Press the OK key.
2. Select the destination.
Initial setting: Inch (Inch specifications)/Europe Metric (Metric specifications)
3. Press the OK key. The setting is set.
4. Turn the main power switch off and on.
U237
Setting finisher stack quantity
Description
Sets the number of sheets of each stack on the main tray and on the Inner tray in 3000-sheet document fin-
isher.
Purpose
To change the setting when a stack malfunction has occurred.
Method
1. Press the OK key.
2. Select the item to be set.
Setting: [Main Tray]
1. Change the setting using the Left/Right Select keys.
Initial setting: 0
2. Press the OK key. The setting is set.
3. Turn the main power switch off and on.
Setting: [Middel Tray]
1. Change the setting using the Left/Right Select keys.
Initial setting: 0
Number of sheets of stack on the internal tray for non-staple copying: 10 sheets
2. Press the OK key. The setting is set.
3. Turn the main power switch off and on.
Maintenance
item No.
Description
Display Description
Auto With no punch unit
Japan Metric Metric (Japan) specifications
Inch Inch (North America) specifications
Europe Metric Metric (Europe) specifications
Display Description
Main Tray Number of sheets of stack on the main tray
Middel Tray Number of sheets of stack on the internal tray for staple mode
Setting value Description
0 Number of sheets of stack on the main tray: 3000 sheets
1 Number of sheets of stack on the main tray: 1500 sheets
Setting value Description
0 Number of sheets of stack on the internal tray for staple mode: 50 sheets
1 Number of sheets of stack on the internal tray for staple mode: 30 sheets

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
