Kyocera FS-C8500DN Service Manual

2KA
1-3-75
U247
Setting the paper feed device
Description
Turns on motor and clutches of 3000-sheet paper feeder or paper feeder.
Purpose
To check the operation of motor and clutches of paper feed device.
Method: 3000-sheet paper feeder
1. Press the OK key.
2. Select [Feed] or [Clutch].
3. Select the item to be operated using the Left/Right Select keys.
4. Press the OK key. The operation starts.
Feed
Clutch
5. To turn each motor off, press the Back key.
Method: Paper feeder
1. Press the OK key.
2. Select [Feed] or [Clutch].
3. Select the item to be operated using the Left/Right Select keys.
4. Press the OK key. The operation starts.
Feed
Clutch
5. To turn each motor off, press the Back key.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Motor and clutches Operation
N/A Not Available -
LCF PF conveying motor (PFCM) In operation
Display Motor and clutches Operation
N/A Not Available -
B PF conveying clutch (PFCCL) On for 1 s
P1 PF paper feed clutch 1 (PFPFCL1) On for 1 s
P2 PF paper feed clutch 2 (PFPFCL2) On for 1 s
Display Motor and clutches Operation
N/A Not Available -
Desk PF drive motor (PFDM) In operation
Clutch PF conveying clutch (PFCCL) On for 1 s
Display Motor and clutches Operation
N/A Not Available -
U PF paper feed clutch 1 (PFPFCL1) On for 1 s
L PF paper feed clutch 2 (PFPFCL2) On for 1 s

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
