Kyocera FS-C8500DN Service Manual

2KA
1-3-78
U253
Switching between double and single counts
Description
Switches the count system for the total counter and other counters for every color mode.
Purpose
Used to select, according to the preference of the user, if A3/Ledger paper is to be counted as one sheet (sin-
gle count) or two sheets (double count).
Setting
1. Press the OK key.
2. Select the item to set.
3. Press the OK key. The screen for setting each item is displayed.
4. Select the count system.
Initial setting: Double (A3/LD)
5. Press the OK key. The setting is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
U260
Selecting the timing for copy counting
Description
Changes the print count timing for the total counter and other counters.
Purpose
To be set according to user request.
Setting
1. Press the OK key.
2. Select the copy count timing.
Initial setting: Eject
3. Press the OK key. The setting is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
Full Color Count system of full color mode
B/W Count system of black/white mode
Display Description
All Single Single count for all size paper
Double (A3/LD) Double count for A3/Ledger size or larger
Double (B4) Double count for B4 size or larger
Double (Folio) Double count for FOLIO/Legal size or larger
Display Description
Feed When secondary paper feed starts
Eject When the paper is ejected

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
