Kyocera FS-C8500DN Service Manual

2KA
1-3-84
U464
Setting the ID correction operation
Description
Turns ID correction (calibration) on or off. Also, this determines the duration of calibration and the timing of
calibration during printing. Also, this allows individual settings for calibration operation by enabling custom set-
tings.
Purpose
To restrict calibration when poor image quality is generated. Also, this allows individual settings for calibration
by enabling custom settings in setting the calibration cycle under the machine defaults depending on the user
preferences.
Performs AC calibration when replacing the developing or drum unit.
Method
1. Press the OK key.
2. Select the item to be set.
3. Press the OK key. The setting screen for the selected item is displayed.
Maintenance
item No.
Description
Display Description
Permit Setting to turn calibration on/off
Time Interval Setting the interval time of calibration after printing
Slp Period Calib Setting the standard time for judging whether or not to carry out calibration
based on the sleep time when the machine recovers from the sleep mode.
Permit Act(50pp) Turning paper interval calibration on/off after continuously printing 50 pages
Permit(On/SlpOut) Setting execution parameters for calibration when powered up or reverted
from auto-sleep
Permit(AP/NE) Paper interval calibration ON/OFF setting at the time of calibration/near end
after toner feed
Calib Tmg Prt Setting the standard time for judging whether or not to carry out calibration
based on the continuous print driving time during printing.
Calib Drv Time Setting the standard time for judging whether or not to carry out paper inter-
val calibration based on the driving time during printing.
Calib Prt Rate Setting the standard printing ratio for judging whether or not to carry out cal-
ibration based on the printing ratio when printing the tenth sheet.
Custom Turning custom settings on/off in setting the calibration cycle under the
menu mode
AC Calib Executing the AC calibration
Target Value Setting the sensor target values for toner thick layer calibration and light
amount calibration
AC Calib Mag AC calibration target bias value setting
Calib Prt Rate(H) Setting the standard printing ratio for judging whether or not to carry out cal-
ibration based on the printing ratio when printing the tenth sheet (half
speed).
Calib Tmg Prt(H) Setting the standard time for judging whether or not to carry out calibration
based on the continuous print driving time during printing (half speed).
AC Calib Type Mode setting for AC calibration bias control
Prt Rate B/W Setting the proportion of black/white printing at which black/white calibra-
tion is executed during color printing.

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
