Kyocera FS-C8500DN Service Manual

2KA
1-3-91
U467
Setting the color registration adjustment
Description
Sets the color registration adjustment and transfer belt speed correction. Also, determines the conditions by
which color registration correction is executed depending on the LSU temperature.
Purpose
If color variance is uneven due to a sensor failure, etc., turn this off and temporarily make a manual adjust-
ment.
Method
1. Press the OK key.
2. Select the item to be set.
3. Press the OK key.
Setting: [Color Reg Adj]
1. Select On or Off.
Initial setting: On
2. Press the OK key. The setting is set.
Setting: [T.B. Speed Adj]
1. Select On or Off.
Initial setting: On
2. Press the OK key. The setting is set.
Setting: [Set Timing]
1. Change the setting value using the Left/Right Select keys.
2. Press the OK key. The value is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
Color Reg Adj Setting the color registration correction operation
T.B. Speed Adj Setting the transfer belt speed correction operation
Set Timing After the previous correction is executed, color registration is com-
pensated as the LSU temperature varies by the value determined.
Display Description
Off Disables the color registration correction operation
On Enables the color registration correction operation
Display Description
Off Disables the transfer belt speed correction operation
On Enables the transfer belt speed correction operation
Display Description Setting range Initial setting
Timing Conditions for execution depending on the
LSU temperature variation
2 to 10 10

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
