Kyocera FS-C8500DN Service Manual

2KA
1-3-96
U902
Checking/clearing finisher punch count
Description
Sets the punch limit and displays and clears the punch-hole scrap count when 3000-sheet document finisher
is installed.
Purpose
Sets the punch limit to notify the user of the time to collect punch-hole scrap. Also, used to manually clear the
punch-hole scrap count if a message requiring collection of punch-hole scrap is shown on the touch panel
after collection. If punch-hole scrap is collected with the machine power turned off, the punch-hole scrap count
is not cleared and consequently this problem occurs.
Setting
1. Press the OK key.
2. Select the item to be set.
3. Change the value using the Left/Right Select keys.
The punch limit can be set in increments of 1000.
4. Press the OK key. The value is set.
Clearing
1. Enter 0 using the Right Select keys.
2. Press the OK key. The count is cleared.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
U903
Checking/clearing the paper jam counts
Description
Displays or clears the jam counts by jam locations.
Purpose
To check the paper jam status. Also to clear the jam counts after replacing consumable parts.
Method
1. Press the OK key.
2. Select the item.
3. Press the OK key.
Method: [Count]
1. The count of jam code by type is displayed.
Codes for which the count value is 0 are not displayed.
2. Change the screen using the cursor up/down keys.
3. Select the counts for all jam codes and select [All Clear].
The individual counter cannot be cleared.
4. Press the OK key. The count is cleared.
Method: [Total Count]
1. The total number of jam code by type is displayed.
2. Change the screen using the cursor up/down keys.
The total number of jam count cannot be cleared.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description Setting range
Limit Punch limit (maximum number of punching times) 0 to 9999000
Count Punch-hole scrap count (current number of punching times) 0 to 9999999
Display Description
Count Displays/clears the jam counts
Total Count Displays the total jam counts
