Kyocera FS-C8500DN Service Manual

2KA
1-4-16
(20)
A paper jam in the
fuser section is indi-
cated during copying
(misfeed in fuser sec-
tion).
Jam code 40 to 46
Broken eject switch 1 actu-
ator.
Check visually and replace switch.
Defective switch. Run maintenance item U031 and turn the following switch on and
off manually. Replace the switch if indication of the corresponding
switch is not displayed in reverse.
Loop sensor, eject switch 1
(21)
A paper jam in the
eject section is indi-
cated during copying
(misfeed in eject sec-
tion).
Jam code 50
Broken switch actuator. Check visually and replace switch.
Defective switch. Run maintenance item U031 and turn the following switch on and
off manually. Replace the switch if indication of the corresponding
switch is not displayed in reverse.
Registration switch, eject switch 1
(22)
A paper jam in the
feedshift section is
indicated during
copying (misfeed in
feedshift section).
Jam code 52
Broken switch actuator. Check visually and replace switch.
Defective switch. Run maintenance item U031 and turn the following switch on and
off manually. Replace the switch if indication of the corresponding
switch is not displayed in reverse.
Eject switch 1, feedshift switch
(23)
A paper jam in the
duplex section is indi-
cated during copying
(misfeed in duplex
paper conveying sec-
tion 1).
Jam code 60
Broken switch actuator. Check visually and replace switch.
Defective switch. Run maintenance item U031 and turn the following switch on and
off manually. Replace the switch if indication of the corresponding
switch is not displayed in reverse.
Feedshift switch, duplex switch, registration switch
(24)
A paper jam in the
duplex section is indi-
cated during copying
(misfeed in duplex
paper conveying sec-
tion 2).
Jam code 61
Broken registration switch
actuator.
Check visually and replace switch.
Defective registration
switch.
Run maintenance item U031 and turn the registration switch on
and off manually. Replace the switch if indication of the corre-
sponding switch is not displayed in reverse.
Defective registration
clutch.
Run maintenance item U032 and select registration clutch to be
turned on and off. Check the status and remedy if necessary.
Electrical problem with reg-
istration clutch.
Check (see page 1-4-63).
Problem
Causes/check procedures Corrective measures

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
