Kyocera FS-C8500DN Service Manual

2KA
1-4-26
C1120 PF left lift position problem (optional
3000-sheet paper feeder)
Level switch 1 does not turn on within 30
s of PF lift motor 1 turning on.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC27 on
the engine PWB and the connector on the
PF main PWB, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective level
switch 1.
Check if YC5-4 on the PF main PWB goes
low when level switch 1 is turned off. If not,
replace PF lift switch 1.
Defective PF lift
motor 1.
Check for continuity across the coil. If none,
replace PF lift motor 1.
The PF left lift does
not rise properly.
Check the gears and belts, and remedy if
necessary.
C1130 PF right lift position problem (optional
3000-sheet paper feeder)
Level switch 2 does not turn on within 30
s of PF lift motor 2 turning on.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC27 on
the engine PWB and the connector on the
PF main PWB, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective level
switch 2.
Check if YC5-7 on the PF main PWB goes
low when level switch 2 is turned off. If not,
replace PF lift switch 2.
Defective PF lift
motor 2.
Check for continuity across the coil. If none,
replace PF lift motor 2.
The PF right lift
does not rise prop-
erly.
Check the gears and belts, and remedy if
necessary.
C1800 Paper feeder communication error
(optional paper feeder)
A communication error from paper
feeder is detected 10 times in succes-
sion.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC27 on
the engine PWB and the connector on the
PF main PWB, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective PWB. Replace the PF main PWB or engine PWB
and check for correct operation.
C1900 Paper feeder EEPROM error (optional
paper feeder)
When writing the data, the write data and
the read data is not continuously in
agreement three times.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC27 on
the engine PWB and the connector on the
PF main PWB, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation.
Defective paper
feeder.
Replace the paper feeder with another unit
and check the operation. If the operation is
normal, replace or repair optional paper
feeder.
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
