Kyocera FS-C8500DN Service Manual

2KA
1-4-25
C1030 PF lift motor 1 error (optional paper
feeder)
After cassette 3 is inserted, PF lift switch
1 does not turn on within 12 s. This error
is detected two times successively.
During driving the motor, the lift overcur-
rent protective monitor signal is detected
for 500 ms or more two times succes-
sively. However, the first 1 s after PF lift
motor 1 is turned on is excluded from
detection.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC27 on
the engine PWB and the connector on the
PF main PWB, and the continuity across the
connector terminals. Repair or replace if
necessary.
Broken gears or
couplings of PF lift
motor 1.
Replace PF lift motor 1.
Defective PF lift
motor 1.
Check for continuity across the coil. If none,
replace PF lift motor 1.
Defective PF lift
switch 1.
Check if YC1-7 on the PF main PWB goes
low when PF lift switch 1 is turned off. If not,
replace PF lift switch 1.
C1040 PF lift motor 2 error (optional paper
feeder)
After cassette 4 is inserted, PF lift switch
2 does not turn on within 12 s. This error
is detected two times successively.
During driving the motor, the lift overcur-
rent protective monitor signal is detected
for 500 ms or more two times succes-
sively. However, the first 1 s after PF lift
motor 2 is turned on is excluded from
detection.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC27 on
the engine PWB and the connector on the
PF main PWB, and the continuity across the
connector terminals. Repair or replace if
necessary.
Broken gears or
couplings of PF lift
motor 2.
Replace PF lift motor 2.
Defective PF lift
motor 2.
Check for continuity across the coil. If none,
replace PF lift motor 2.
Defective PF lift
switch 2.
Check if YC1-9 on the PF main PWB goes
low when PF lift switch 2 is turned off. If not,
replace PF lift switch 2.
C1100 PF lift motor 1 error (optional 3000-
sheet paper feeder)
A motor over-current signal is detected
continuously for 1 s or longer.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC27 on
the engine PWB and the connector on the
PF main PWB, and the continuity across the
connector terminals. Repair or replace if
necessary.
PF lift motor 1 does
not rotate correctly
(the motor is over-
loaded).
Check the gears and remedy if necessary.
C1110 PF lift motor 2 error (optional 3000-
sheet paper feeder)
A motor over-current signal is detected
continuously for 1 s or longer.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC27 on
the engine PWB and the connector on the
PF main PWB, and the continuity across the
connector terminals. Repair or replace if
necessary.
PF lift motor 2 does
not rotate correctly
(the motor is over-
loaded).
Check the gears and remedy if necessary.
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
