Kyocera FS-C8500DN Service Manual

2KA
1-4-24
C0800 Image processing problem
JAM05 is detected twice.
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
C0840 Faults of RTC
The time is judged to go back based on
the comparison of the RTC time and the
current time or five years or more have
passed.
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
The battery is dis-
connected from the
main PWB.
Check visually and remedy if necessary.
C1010 Lift motor 1 error
After cassette 1 is inserted, lift switch 1
does not turn on within 12 s. This error is
detected four times successively.
Poor contact in the
connector termi-
nals.
Check the connection of connector of lift
motor 1 and the connector YC3 on the feed
PWB, and the continuity across the connec-
tor terminals. Repair or replace if necessary.
Broken gears or
couplings of lift
motor 1.
Replace lift motor 1.
Defective lift motor
1.
Check for continuity across the coil. If none,
replace lift motor 1.
Defective lift switch
1.
Check if YC4-2 on the feed PWB goes low
when lift switch 1 is turned off. If not, replace
lift switch 1.
Poor contact in the
connector termi-
nals.
Check the connection of connector of lift
switch 1 and the connector YC4 on the feed
PWB, and the continuity across the connec-
tor terminals. Repair or replace if necessary.
Defective PWB. Replace the feed PWB or engine PWB and
check for correct operation.
C1020 Lift motor 2 error
After cassette 2 is inserted, lift switch 2
does not turn on within 12 s. This error is
detected four times successively.
Poor contact in the
connector termi-
nals.
Check the connection of connector of lift
motor 2 and the connector YC3 on the feed
PWB, and the continuity across the connec-
tor terminals. Repair or replace if necessary.
Broken gears or
couplings of lift
motor 2.
Replace lift motor 2.
Defective lift motor
2.
Check for continuity across the coil. If none,
replace lift motor 2.
Defective lift switch
2.
Check if YC4-8 on the feed PWB goes low
when lift switch 2 is turned off. If not, replace
lift switch 2.
Poor contact in the
connector termi-
nals.
Check the connection of connector of lift
switch 2 and the connector YC4 on the feed
PWB, and the continuity across the connec-
tor terminals. Repair or replace if necessary.
Defective PWB. Replace the feed PWB or engine PWB and
check for correct operation.
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
