Kyocera FS-C8500DN Service Manual

2KA
1-4-33
C2300 Fuser motor error
After the motor drive ON signal is output
and 1 s elapses, the rated speed reach
signal is not input continuously for 2 s.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC25 on
the engine PWB and the connector of the
fuser motor, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective drive
transmission sys-
tem.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective fuser
motor.
Run maintenance item U030 and check if
the fuser motor operates when YC25-B4
(remote signal) on the engine PWB goes
low. If not, replace the fuser motor.
Defective engine
PWB.
Run maintenance item U030 and check if
YC25-B4 (remote signal) on the engine
PWB goes low. If not, replace the engine
PWB.
C2351 Cleaning motor K error
After the motor drive ON signal is output
and 2 s elapses, the rated speed reach
signal is not input continuously for 1 s.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC16 on
the engine PWB and the connector of the
cleaning motor K, and the continuity across
the connector terminals. Repair or replace if
necessary.
Defective drive
transmission sys-
tem.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective cleaning
motor K.
Run maintenance item U030 and check if
the cleaning motor K operates when YC16-
B13 (remote signal) on the engine PWB
goes low. If not, replace the cleaning motor
K.
Defective engine
PWB.
Run maintenance item U030 and check if
YC16-B13 (remote signal) on the engine
PWB goes low. If not, replace the engine
PWB.
C2352 Cleaning motor MCY error
After the motor drive ON signal is output
and 2 s elapses, the rated speed reach
signal is not input continuously for 1 s.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC16 on
the engine PWB and the connector of the
cleaning motor MCY, and the continuity
across the connector terminals. Repair or
replace if necessary.
Defective drive
transmission sys-
tem.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective cleaning
motor K.
Run maintenance item U030 and check if
the cleaning motor MCY operates when
YC16-A13 (remote signal) on the engine
PWB goes low. If not, replace the cleaning
motor MCY.
Defective engine
PWB.
Run maintenance item U030 and check if
YC16-A13 (remote signal) on the engine
PWB goes low. If not, replace the engine
PWB.
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
