Kyocera FS-C8500DN Service Manual

2KA
1-4-37
C5104 Main high-voltage Y error
Abnormality of charger roller Y is
detected when Vpp adjustment.
Installation defec-
tiveness on
charger roller unit
Y.
Check the mounting state of the charger
roller unit Y. If any problem is found, repair
or replace the unit.
Defective charger
roller unit Y.
Replace the charger roller unit Y (see page
1-5-27).
C5301 Cleaning lamp K error Poor contact in the
connector termi-
nals.
Check the connection of connector YC3 on
the main front PWB and the connector of the
drum unit K, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective clean-
ing lamp K.
Replace the drum unit K (see page 1-5-26).
Defective PWB. Replace the main front PWB or engine PWB
and check for correct operation.
C5302 Cleaning lamp C error Poor contact in the
connector termi-
nals.
Check the connection of connector YC5 on
the sub front PWB and the connector of the
drum unit C, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective cleaning
lamp C.
Replace the drum unit C (see page 1-5-26).
Defective PWB. Replace the sub front PWB or engine PWB
and check for correct operation.
C5303 Cleaning lamp M error Poor contact in the
connector termi-
nals.
Check the connection of connector YC7 on
the sub front PWB and the connector of the
drum unit M, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective cleaning
lamp M.
Replace the drum unit M (see page 1-5-26).
Defective PWB. Replace the sub front PWB or engine PWB
and check for correct operation.
C5304 Cleaning lamp Y error Poor contact in the
connector termi-
nals.
Check the connection of connector YC3 on
the sub front PWB and the connector of the
drum unit Y, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective cleaning
lamp Y.
Replace the drum unit Y (see page 1-5-26).
Defective PWB. Replace the sub front PWB or engine PWB
and check for correct operation.
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
