Kyocera FS-C8500DN Service Manual

2KA
1-4-53
C8910 Punch backup memory data problem
(optional of 3000-sheet document fin-
isher)
Read and write data does not match 3
times in succession.
Poor contact in the
connector termi-
nals.
Check the connection of connector on the
punch PWB and the connector YC4 on the
finisher main PWB, and the continuity
across the connector terminals. Repair or
replace if necessary.
Defective punch
PWB.
Replace the punch PWB and check for cor-
rect operation.
C8920 Mailbox backup memory data prob-
lem (optional mailbox of 3000-sheet
document finisher)
Read and write data does not match 3
times in succession.
Poor contact in the
connector termi-
nals.
Check the connection of connector on the
mailbox main PWB and the connector YC7
on the finisher main PWB, and the continuity
across the connector terminals. Repair or
replace if necessary.
Defective mailbox
main PWB.
Replace the mailbox main PWB and check
for correct operation.
C8930 Center-folding backup memory data
problem (optional center-folding unit
of 3000-sheet document finisher)
Read and write data does not match 3
times in succession.
Poor contact in the
connector termi-
nals.
Check the connection of connector on the
centerfold main PWB and the connector
YC5 on the finisher main PWB, and the con-
tinuity across the connector terminals.
Repair or replace if necessary.
EEPROM installed
incorrectly.
Install EEPROM correctly.
Defective center-
fold main PWB.
Replace the centerfold main PWB and
check for correct operation.
C9530 Contact the Service Administrative Division.
C9540 Contact the Service Administrative Division.
C9550 Contact the Service Administrative Division.
F000 Operation panel PWB communication
error
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
Defective opera-
tion panel PWB.
Replace the operation panel PWB and
check for correct operation.
F020 Memory checksum error Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
Defective expan-
sion memory.
Replace the expansion memory and check
for correct operation.
F040 Engine PWB communication error Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation.
F050
Engine ROM checksum error Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation.
F278 Power source PWB secondary side
error
Defective power
source PWB.
Replace the power source PWB and check
for correct operation.
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
