Kyocera FS-C8500DN - Page 246

2KA
1-5-24
10. Remove the image formation holder.
When refitting the image formation holder,
first insert the left pin into the machine and
then insert the right pin.
Figure 1-5-42
Pin
(right side)
Pin
(left side)
formation holder
formation holder
formation holder
