Kyocera FS-C8500DN Service Manual

2KA
2-3-3
YC8 1 +12V O 12 V DC 24 V DC power to HDD
Connected to
the hard disk
2 +12V O 12 V DC 24 V DC power to HDD
3 +5V O 5 V DC 5 V DC power to HDD
4 +5V O 5 V DC 5 V DC power to HDD
5 GND - - Ground
6 GND - - Ground
7 GND - - Ground
8 GND - - Ground
YC10 1 FSR_RELAY I 0/3.3 V DC Relay signal
Connected to
the engine
PWB
2 24V2IN I 24 V DC 24 V DC power input (via left cover 1 switch)
3 SLEEPN I 0/3.3 V DC Sleep signal: On/Off
4 ZCROSSC O 0/3.3 V DC (pulse) Zero-cross signal
5 S_HEATN I 0/3.3 V DC FH2: On/Off
6 M_HEATN I 0/3.3 V DC FH1: On/Off
7 PR_HEATN I 0/3.3 V DC FH3: On/Off
8 FAN_REM I 0/24 V DC PSFM: On/Off
9 GND - - Ground
10 GND - - Ground
11 5V3 O 5 V DC 5 V DC power to EPWB
12 5V3 O 5 V DC 5 V DC power to EPWB
13 D_HEATN - - Not used
YC12 1 GND - - Ground
Connected to
the optional
document fin-
isher
2 GND - - Ground
3 GND - - Ground
4 GND - - Ground
5 GND - - Ground
6 GND - - Ground
YC13
1 +24V1 O 24 V DC 24 V DC power to paper feeder
Connected to
the optional
paper feeder
and optional
document fin-
isher
2 +24V1 O 24 V DC 24 V DC power to document finisher
3 GND - - Ground
4 GND - - Ground
5 GND - - Ground
6 GND - - Ground
7 +5V1 O 5 V DC 5 V DC power to paper feeder
8 +5V1 O 5 V DC 5 V DC power to document finisher
9 NC - - Not used
Connector Pin No. Signal I/O Voltage Description

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
