Kyocera FS-C8500DN - Page 300

2KA
2-3-2
Connector Pin No. Signal I/O Voltage Description
TB
1 AC_LIVE I 120 V AC
220-240 V AC
AC power input
Connected to
the inlet and
main power
switch
2 AC_NEUTRAL I 120 V AC
220-240 V AC
AC power input
3 HEATER LIVE - - Not used
YC1
1 MSW_IN I 120 V AC
220-240 V AC
AC power input from MSW
Connected to
the main
power switch
2 MSW_OUT O 120 V AC
220-240 V AC
AC power input from MSW
YC3
1 DH3_LIVE O 120 V AC
220-240 V AC
AC power output to CH1
Connected to
the cassette
heater 1/2
2 DH3_LIVE O 120 V AC
220-240 V AC
AC power output to CH2
3 NC - - Not used
4 NC - - Not used
5 DH3_NEUTRAL O 120 V AC
220-240 V AC
AC power output to CH1
6 DH3_NEUTRAL O 120 V AC
220-240 V AC
AC power output to CH2
YC4
1 H_LIVE O 120 V AC
220-240 V AC
AC power to FH1/2/3
Connected to
the fuser
heater 1/2/3
2 SH_OUT O 120 V AC
220-240 V AC
FH2: On/Off
3 PR_OUT O 120 V AC
220-240 V AC
FH3: On/Off
4 MH_OUT O 120 V AC
220-240 V AC
FH1: On/Off
YC6 1 5V O 5 V DC 5 V DC power to MPWB
Connected to
the main
PWB
2 5V O 5 V DC 5 V DC power to MPWB
3 5V O 5 V DC 5 V DC power to MPWB
4 5V O 5 V DC 5 V DC power to MPWB
5 GND - - Ground
6 GND - - Ground
7 GND - - Ground
8 GND - - Ground
YC7 1 +24V1 O 24 V DC 24 V DC power to EPWB
Connected to
the engine
PWB
2 +24V1 O 24 V DC 24 V DC power to EPWB
3 GND - - Ground
4 GND - - Ground
5 GND - - Ground
6 +5V1 O 5 V DC 5 V DC power to EPWB
