Kyocera FS-C8500DN Service Manual

2KA
2-3-15
YC20 B5 MPF2 JAM I 0/3.3 V DC MPPCSW: On/Off
Connected to
the feed PWB
B6 FEED1 JAM I 0/3.3 V DC FSW1: On/Off
B7 ROL UP2 CLT
REM
O 0/24 V DC MCL: On/Off
B8 REG UP1 CLT
REM
O 0/24 V DC RCL: On/Off
B9 LOOP SENS I 0/3.3 V DC LS: On/Off
B10 BELT JAM I 0/3.3 V DC JDS: On/Off
B11 DU ENTER JAM I 0/3.3 V DC FSSW: On/Off
B12 JAM1 LED O 0/3.3 V DC JLEDPWB1 LED emitter signal
B13 JAM2 LED O 0/3.3 V DC JLEDPWB2 LED emitter signal
B14 COV FAN REM - - Not used
B15 DU OPEN I 0/3.3 V DC LC1SW: On/Off
B16 DU JAM I 0/3.3 V DC DUSW: On/Off
B17 FEED3 JAM I 0/3.3 V DC FSW3: On/Off
B18 FEED2 JAM I 0/3.3 V DC FSW2: On/Off
B19 CAS OPEN I 0/3.3 V DC LC2SW: On/Off
B20 DU MT PD O 0/3.3 V DC DUM current control signal
YC21 1 +24V2 O 24 V DC 24 V DC power to FPWB
Connected to
the feed PWB
2 +24V2 O 24 V DC 24 V DC power to FPWB
3 +24V2 O 24 V DC 24 V DC power to FPWB
4PGND -- Ground
5PGND -- Ground
6PGND -- Ground
7PGND -- Ground
8 +5V1 O 5 V DC 5 V DC power to FPWB
YC22 1 REG MT CLK O 0/3.3 V DC (pulse) RM clock signal
Connected to
the feed PWB
2 REG MT DR O 0/3.3 V DC RM: On/Off
3 REG MT PD O 0/3.3 V DC RM current control signal
4 ROL MT CLK O 0/3.3 V DC (pulse) MM clock signal
5 ROL MT DR O 0/3.3 V DC MM: On/Off
6 ROL MT PD O 0/3.3 V DC MM current control signal
YC23 1 5V SENSOR LED O 5 V DC 5 V DC power to MPPLSW
Connected to
the MP paper
size length
switch, MP
tray switch,
MP paper
size width
switch, MP
paper switch,
MP paper
feed switch,
MP solenoid
and Mp paper
feed clutch
2 MPF LENGTH I 0/3.3 V DC MPPLSW: On/Off
3PGND -- Ground
4 MPF TABLE I 0/3.3 V DC MPTSW: On/Off
5PGND -- Ground
6 MPF_WIDTH1 I 0/3.3 V DC MPPWSW: On/Off
7 MPF_WIDTH2 I 0/3.3 V DC MPPWSW: On/Off
8 MPF_WIDTH3 I 0/3.3 V DC MPPWSW: On/Off
9PGND -- Ground
10 PGND - - Ground
11 MPF PPR SET I 0/3.3 V DC MPPSW: On/Off
12 +5V1 O 5 V DC 5 V DC power to MPPSW
Connector Pin No. Signal I/O Voltage Description

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
