Kyocera FS-C8500DN Service Manual

2KA
2-3-17
YC26 A5
CONTAIN_MT_CLK O 0/3.3 V DC (pulse) TCM clock signal
Connected to
the toner con-
tainer motor,
developing
fan motor 3/4
and toner
motor M/C/Y/
K
A6
CONTAIN_MT_DIR O 0/3.3 V DC TCM drive switch signal
A7 CONTAIN_MT_DR O 0/3.3 V DC TCM: On/Off
A8
CONTAIN_MT_RDY I 0/3.3 V DC TCM ready signal
A9 PGND - - Ground
A10 PGND - - Ground
A11 +24V1 O 24 V DC 24 V DC power to TCM
A12 +24V1 O 24 V DC 24 V DC power to TCM
B1 SUB_DLP_FAN O 0/24 V DC DEVFM4: On/Off
B2 +24V1 O 24 V DC 24 V DC power to DEVFM4
B3 TMOT1 DR O 0/24 V DC TM-M: On/Off
B4 TMOT1RTN I Analog TM-M return signal
B5 TMOT2 DR O 0/24 V DC TM-C: On/Off
B6 TMOT2RTN I Analog TM-C return signal
B7 TMOT3 DR O 0/24 V DC TM-Y: On/Off
B8 RMOT3RTN I Analog TM-Y return signal
B9 TMOT4 DR O 0/24 V DC TM-K: On/Off
B10 TMOT4RTN I Analog TM-K return signal
B11 REAR DLP FAN O 0/24 V DC DEVFM3: On/Off
B12 +24V1 O 24 V DC 24 V DC power to DEVFM3
YC27 1 EH RDY (PFRDY) I 0/5 V DC Paper feeder ready signal
Connected to
the optional
paper feeder
and optional
document fin-
isher
2 EH RDY (DF RDY) I 0/5 V DC Document finisher ready signal
3 PF FEED O 0/5 V DC Paper feeder control signal
4 PF SEL O 0/5 V DC Paper feeder select signal
5 DF SEL O 0/5 V DC Document finisher select signal
6EH SCLK (PFS-
CLK)
O 0/5 V DC (pulse) Paper feeder clock signal
7EH SCLK (DFS-
CLK)
O 0/5 V DC (pulse) Document finisher clock signal
8 EHSDI (PFSDI) I 0/5 V DC (pulse) Serial communication data signal
9 EH SDI (DFSDI) I 0/5 V DC (pulse) Serial communication data signal
10 EH SDO (PFSDO) O 0/5 V DC (pulse) Serial communication data signal
11 EH SDO (DFSDO) O 0/5 V DC (pulse) Serial communication data signal
12 DF DET I 0/5 V DC Document finisher set signal
Connector Pin No. Signal I/O Voltage Description

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
