2KA
2-3-18
YC28 A1 +5V1 O 5 V DC 5 V DC power to EJPWB
Connected to
the eject
PWB, top
cover switch,
eject fan
motor, trans-
fer belt speed
PWB, trans-
fer position
sensor, color
release sen-
sor, color
release motor
and transfer
fan motor 2/3
A2 JOB EXIT JAM2 I 0/5 V DC FSSW: On/Off
A3 JOB EXIT JAM1 - - Not used
A4 SGND - - Ground
A5 PGND - - Ground
A6 PGND - - Ground
A7 JOB EJECT I 0/5 V DC TCSW: On/Off
A8 JOB SOL2 DR O 0/24 V DC FSSOL1: On/Off (ACT)
A9 JOB SOL1 DR O 0/24 V DC FSSOL1: On/Off (REV)
A10 +24V2 O 24 V DC 24 V DC power to EJPWB
A11 +24V2 O 24 V DC 24 V DC power to EJPWB
A12 JOB MOT DR O 0/24 V DC FSM: On/Off
A13 JOB MOT CLK O 0/5 V DC (pulse) FSM clock signal
A14 JOB MOT MODE O 0/5 V DC FSM mode signal
A15 JOB MOT DIR - - Not used
A16 JOB_SET - - Not used
A17 REAR_FAN O 0/24 V DC EFM: On/Off
A18 24V2 O 24 V DC 24 V DC power to EFM
B1 +5V1 O 5 V DC 5 V DC power to TBSPWB
B2 BLT SPEED I 0/3.3 V DC (pulse) TBSPWB detection signal
B3 +3.3V1 O 3.3 V DC 3.3 V DC power to TBSPWB
B4 EEP SDA0 I/O 0/3.3 V DC (pulse) TBSPWB EEPROM data signal
B5 EEP SCL0 O 0/3.3 V DC (pulse) TBSPWB EEPROM clock signal
B6 SGND - - Ground
B7 SGND - - Ground
B8 BLT SET I 0/5 V DC TPS: On/Off
B9 +5V1 O 5 V DC 5 V DC power to TPS
B10 SGND - - Ground
B11 RLS SET I 0/5 V DC CRS: On/Off
B12 +5V1 O 5 V DC 5 V DC power to CRS
B13 RLS MT DR O 0/24 V DC CRM: On/Off
B14 RLS MT RTN O 0/24 V DC CRM: On/Off
B15 BLT FAN1 O 0/24 V DC TRFM2: On/Off
B16 +24V2 O 24 V DC 24 V DC power to TRFM2
B17 BLT FAN2 O 0/24 V DC TRFM3: On/Off
B18 +24V2 O 24 V DC 24 V DC power to TRFM3
Connector Pin No. Signal I/O Voltage Description
