Kyocera FS-C8500DN Service Manual

2KA
2-3-22
YC3 37 VD B1 N O 0/3.3 V DC (pulse) Image control signal
Connected to
the engine
PWB
38 VD C1 N O 0/3.3 V DC (pulse) Image control signal
39 VD B2 P O 0/3.3 V DC (pulse) Image control signal
40 VD C2 P O 0/3.3 V DC (pulse) Image control signal
41 VD B2 N O 0/3.3 V DC (pulse) Image control signal
42 VD C2 N O 0/3.3 V DC (pulse) Image control signal
43 VD B3 P O 0/3.3 V DC (pulse) Image control signal
44 VD C3 P O 0/3.3 V DC (pulse) Image control signal
45 VD B3 N O 0/3.3 V DC (pulse) Image control signal
46 VD C3 N O 0/3.3 V DC (pulse) Image control signal
47 VCLKOUT P O 0/3.3 V DC (pulse) Image control signal
48 GND - - Ground
49 VCLKOUT N O 0/3.3 V DC (pulse) Image control signal
50 GND - - Ground
YC4 1 GND - - Ground
Connected to
the engine
PWB
2 GND - - Ground
3 HSYNCDN P I 0/3.3 V DC (pulse) Image control signal
4 VSYNCD P I 0/3.3 V DC (pulse) Image control signal
5 HSYNCDN N I 0/3.3 V DC (pulse) Image control signal
6 VSYNCD N I 0/3.3 V DC (pulse) Image control signal
7 HSYNCCN P I 0/3.3 V DC (pulse) Image control signal
8 VSYNCC P I 0/3.3 V DC (pulse) Image control signal
9 HSYNCCN N I 0/3.3 V DC (pulse) Image control signal
10 VSYNCC N I 0/3.3 V DC (pulse) Image control signal
11 HSYNCBN P I 0/3.3 V DC (pulse) Image control signal
12 VSYNCB P I 0/3.3 V DC (pulse) Image control signal
13 HSYNCBN N I 0/3.3 V DC (pulse) Image control signal
14 VSYNCB N I 0/3.3 V DC (pulse) Image control signal
15 HSYNCAN P I 0/3.3 V DC (pulse) Image control signal
16 VSYNCA P I 0/3.3 V DC (pulse) Image control signal
17 HSYNCAN N I 0/3.3 V DC (pulse) Image control signal
18 VSYNCA N I 0/3.3 V DC (pulse) Image control signal
19 GND - - Ground
20 GND - - Ground
21 EG_IRN I 0/3.3 V DC EPWB interrupt signal
22 NC - - Not used
23 EG_SO I 0/3.3 V DC (pulse) EPWB serial communication data signal
24 NC - - Not used
25 EG_SDIR I 0/3.3 V DC EPWB communication direction signal
26 NC - - Not used
27 EG_SBSY I 0/3.3 V DC EPWB busy signal
28 NC - - Not used
29 +24V DOWN I 0/3.3 V DC EPWB 24 V down signal
30 NC - - Not used
Connector Pin No. Signal I/O Voltage Description

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
