Kyocera FS-C8500DN - Page 321

2KA
2-3-23
YC5-1 1 CT O 3.3 V DC 3.3 V DC power output
Connected to
the ethernet
2 TD+ O 0/3.3 V DC (pulse) Transmission data
3 TD- O 0/3.3 V DC (pulse) Transmission data
4 RD+ I 0/3.3 V DC (pulse) Received data
5 RD- I 0/3.3 V DC (pulse) Received data
6 CT O 3.3 V DC 3.3 V DC power output
7 CAT PHY O 0/3.3 V DC Control signal
8 ANO PHY O 3.3 V DC 3.3 V DC power output
9 CAT MAC - - Ground
10 ANO MAC O 0/3.3 V DC Control signal
YC5-2 U1 VBUS I 5 V DC 5 V DC power input
Connected to
the USB
U2 DATA- I/O - USB data signal
U3 DATA+ I/O - USB data signal
U4 GND - - Ground
YC8 1 GND - - Ground
Connected to
the interface
PWB
2 AUDIO I Analog AUDIO signal
3 SEL AUDIO0 O 0/3.3 V DC SEL AUDIO0 signal
4 SEL AUDIO1 O 0/3.3 V DC SEL AUDIO1 signal
5 _REG I 0/3.3 V DC REG signal
6 A8 O 0/3.3 V DC (pulse) Address bus signal
7 A15 O 0/3.3 V DC (pulse) Address bus signal
8 A7 O 0/3.3 V DC (pulse) Address bus signal
9 A14 O 0/3.3 V DC (pulse) Address bus signal
10 A6 O 0/3.3 V DC (pulse) Address bus signal
11 A13 O 0/3.3 V DC (pulse) Address bus signal
12 A5 O 0/3.3 V DC (pulse) Address bus signal
13 A12 O 0/3.3 V DC (pulse) Address bus signal
14 A4 O 0/3.3 V DC (pulse) Address bus signal
15 A11 O 0/3.3 V DC (pulse) Address bus signal
16 A3 O 0/3.3 V DC (pulse) Address bus signal
17 A10 O 0/3.3 V DC (pulse) Address bus signal
18 A2 O 0/3.3 V DC (pulse) Address bus signal
19 A9 O 0/3.3 V DC (pulse) Address bus signal
20 A1 O 0/3.3 V DC (pulse) Address bus signal
21 GND - - Ground
22 GND - - Ground
23 D8 I/O 0/3.3 V DC (pulse) Data bus signal
24 D0 I/O 0/3.3 V DC (pulse) Data bus signal
25 D9 I/O 0/3.3 V DC (pulse) Data bus signal
26 D1 I/O 0/3.3 V DC (pulse) Data bus signal
27 D10 I/O 0/3.3 V DC (pulse) Data bus signal
28 D2 I/O 0/3.3 V DC (pulse) Data bus signal
Connector Pin No. Signal I/O Voltage Description
