Kyocera FS-C8500DN Service Manual

2KA
2-3-24
YC8 29 D11 I/O 0/3.3 V DC (pulse) Data bus signal
Connected to
the interface
PWB
30 D3 I/O 0/3.3 V DC (pulse) Data bus signal
31 GND - - Ground
32 GND - - Ground
33 D12 I/O 0/3.3 V DC (pulse) Data bus signal
34 D4 I/O 0/3.3 V DC (pulse) Data bus signal
35 D13 I/O 0/3.3 V DC (pulse) Data bus signal
36 D5 I/O 0/3.3 V DC (pulse) Data bus signal
37 D14 I/O 0/3.3 V DC (pulse) Data bus signal
38 D6 I/O 0/3.3 V DC (pulse) Data bus signal
39 D15 I/O 0/3.3 V DC (pulse) Data bus signal
40 D7 I/O 0/3.3 V DC (pulse) Data bus signal
41 GND - - Ground
42 GND - - Ground
43 KUIODREQT0 I 0/3.3 V DC (pulse) KUIODREQT0 signal
44 KUIODREQT1 I 0/3.3 V DC (pulse) KUIODREQT1 signal
45 KUIODREQR0 I 0/3.3 V DC (pulse) KUIODREQR0 signal
46 KUIODREQR1 I 0/3.3 V DC (pulse) KUIODREQR1 signal
47 KUIOIORN0 O 0/3.3 V DC (pulse) KUIOIORN0 signal
48 KUIOIORN1 O 0/3.3 V DC (pulse) KUIOIORN1 signal
49 KUIOIOWN0 O 0/3.3 V DC (pulse) KUIOIOWN0 signal
50 KUIOIOWN1 O 0/3.3 V DC (pulse) KUIOIOWN1 signal
YC9 1 KUIOCSN0 O 0/3.3 V DC (pulse) KUIOCSN0 signal
Connected to
the interface
PWB
2 KUIOCSN1 O 0/3.3 V DC (pulse) KUIOCSN1 signal
3 KUIOACKN0 I 0/3.3 V DC (pulse) KUIOACKN0 signal
4 KUIOACKN1 I 0/3.3 V DC (pulse) KUIOACKN1 signal
5 KUIOIRN0 I 0/3.3 V DC KUIOIRN0 signal
6 KUIOIRN1 I 0/3.3 V DC KUIOIRN1 signal
7 KUIORDY0 O 0/3.3 V DC KUIORDY0 signal
8 KUIORDY1 O 0/3.3 V DC KUIORDY1 signal
9 GND - - Ground
10 GND - - Ground
11 KUIODACKRN0 O 0/3.3 V DC (pulse) KUIODACKRN0 signal
12 KUIODACKRN1 O 0/3.3 V DC (pulse) KUIODACKRN1 signal
13 KUIODACKTN0 O 0/3.3 V DC (pulse) KUIODACKTN0 signal
14 KUIODACKTN1 O 0/3.3 V DC (pulse) KUIODACKTN1 signal
15 KUIORSTN0 O 0/3.3 V DC KUIORSTN0 signal
16 KUIORSTN1 O 0/3.3 V DC KUIORSTN1 signal
17 GND - - Ground
18 GND - - Ground
19 SLEEP O 0/3.3 V DC SLEEP signal
20 CFOEN0 O 0/3.3 V DC (pulse) CFOEN0 signal
Connector Pin No. Signal I/O Voltage Description

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
