Kyocera FS-C8500DN - Page 328

2KA
2-3-30
YC6 1 +3.3V1 O 3.3 V DC 3.3 V DC power to FRPWB-S
Connected to
the sub front
PWB
2 +5V1 O 5 V DC 5 V DC power to FRPWB-S
3 +24V1 O 24 V DC 24 V DC power to FRPWB-S
4 EEP SCLK O 0/3.3 V DC (pulse) EEPROM clock signal
5 EEP SDA I/O 0/3.3 V DC (pulse) EEPROM data signal
6 FRONT OPEN I 0/3.3 V DC FCSW: On/Off
7 GND - - Ground
8 GND - - Ground
9 GND - - Ground
YC7 1 +24V1 O 24 V DC 24 V DC power to CFM
Connected to
the container
fan motor
2 CONTAIN_FAN O 0/24 V DC CFM: On/Off
Connector Pin No. Signal I/O Voltage Description
