Kyocera FS-C8500DN - Page 327

2KA
2-3-29
YC4 1 GND - - Ground
Connected to
the develop-
ing PWB K
2 SDA I/O 0/3.3 V DC (pulse) DEVPWB-K EEPROM data signal
3 SCK O 0/3.3 V DC (pulse) DEVPWB-K EEPROM clock signal
4 +3.3V1 O 3.3 V DC 3.3 V DC power to DEVPWB-K
5 TPD4 I Analog TS-K detection signal
6 +24V1 O 24 V DC 24 V DC power to DEVPWB-K
7 VCONT 4 O Analog TS-K control signal
YC5 A1 GND - - Ground
Connected to
the engine
PWB
A2 GND - - Ground
A3 GND - - Ground
A4 +24V1 I 24 V DC 24 V DC power from EPWB
A5 GND - - Ground
A6 +5V3 I 5 V DC 5 V DC power from EPWB
A7 PGND - - Ground
A8 PGND - - Ground
A9 +5V1 I 5 V DC 5 V DC power from EPWB
A10 VCONT K I Analog TS-K control signal
A11 TPD1 K O Analog TS-K detection signal
A12 FRONT_FAN I 0/24 V DC FRFM: On/Off
A13 POS SENS K O 0/3.3 V DC DPS-K: On/Off
A14 ERS K I 24/0 V DC CL-K: On/Off
A15 +3.3V1 I 3.3 V DC 3.3 V DC power from EPWB
A16 PGND - - Ground
A17 +24V2 I 24 V DC 24 V DC power from EPWB
A18 +24V2 I 24 V DC 24 V DC power from EPWB
A19 +24V2 I 24 V DC 24 V DC power from EPWB
B1 EEP SCL 1 I 0/3.3 V DC (pulse) EEPROM clock signal
B2 EEP SDA 1 I/O 0/3.3 V DC (pulse) EEPROM data signal
B3 FRONTOPEN O 0/3.3 V DC FCSW: On/Off
B4 HUMIDSCL I 0/3.3 V DC (pulse) OUTTEMS EEPROM clock signal
B5 HUMIDSDA O 0/3.3 V DC (pulse) OUTTEMS EEPROM data signal
B6 MT_PD I 0/3.3 V DC RGM control signal
B7 T2REM I 0/3.3 V DC Secondary transfer bias: On/Off
B8 T2CONT I Analog Secondary transfer bias control voltage
B9 T2INVCONT I Analog Secondary transfer (reverse) bias control voltage
B10 SEPREM I 0/3.3 V DC Separation bias: On/Off
B11 SEPCONT I Analog Separation bias control voltage
B12 JOB_LED - - Not used
B13 JOB_EXIST O 0/3.3 V DC PFS: On/Off
B14 FUSER PI O 0/3.3 V DC ESW1: On/Off
B15 GUIDE PI O 0/3.3 V DC ESW2: On/Off
B16 MT DR - - Not used
B17 MT CLK - - Not used
B18 MT DIR - - Not used
B19 CONTAIN FAN I 0/24 V DC CFM: On/Off
Connector Pin No. Signal I/O Voltage Description
