YC5 1 ERASER C O 24 V DC 24 V DC power to CL-C
Connected to
the cleaning
lamp C, drum
PWB C and
drum position
sensor C
2 ERS DR O 24/0 V DC CL-C: On/Off
3 +3.3V1 O 3.3 V DC 3.3 V DC power to DRPWB-C
4 EEP SCL O 0/3.3 V DC (pulse) DRPWB-C EEPROM clock signal
5 EEPSDA I/O 0/3.3 V DC (pulse) DRPWB-C EEPROM data signal
6 GND - - Ground
7 A1(OPEN) - - Not used
8 A0(GND) - - Ground
9 +5V1 O 5 V DC 5 V DC power to DPS-C
10 POS SENS 2 I 0/3.3 V DC DPS-C: On/Off
11 GND - - Ground
YC6 1 GND - - Ground
Connected to
the develop-
ing PWB C
2 SDA I/O 0/3.3 V DC (pulse) DEVPWB-C EEPROM data signal
3 SCK O 0/3.3 V DC (pulse) DEVPWB-C EEPROM clock signal
4 +3.3V1 O 3.3 V DC 3.3 V DC power to DEVPWB-C
5 TPD2 I Analog TS-C detection signal
6 +24V1 O 24 V DC 24 V DC power to DEVPWB-C
7 VCONT 2 O Analog TS-C control signal
YC7 1 ERASER M O 24 V DC 24 V DC power to CL-M
Connected to
the cleaning
lamp M, drum
PWB M and
drum position
sensor M
2 ERS DR O 24/0 V DC CL-M: On/Off
3 +3.3V1 O 3.3 V DC 3.3 V DC power to DRPWB-M
4 EEP SCL O 0/3.3 V DC (pulse) DRPWB-M EEPROM clock signal
5 EEPSDA I/O 0/3.3 V DC (pulse) DRPWB-M EEPROM data signal
6 GND - - Ground
7 A0(GND) - - Ground
8 A0(GND) - - Ground
9 +5V1 O 5 V DC 5 V DC power to DPS-M
10 POS SENS 1 I 0/3.3 V DC DPS-M: On/Off
11 GND - - Ground
YC8 1 GND - - Ground
Connected to
the develop-
ing PWB M
2 SDA I/O 0/3.3 V DC (pulse) DEVPWB-M EEPROM data signal
3 SCK O 0/3.3 V DC (pulse) DEVPWB-M EEPROM clock signal
4 +3.3V1 O 3.3 V DC 3.3 V DC power to DEVPWB-M
5 TPD1 I Analog TS-M detection signal
6 +24V1 O 24 V DC 24 V DC power to DEVPWB-M
7 VCONT 1 O Analog TS-M control signal
Connector Pin No. Signal I/O Voltage Description
