Connector Pin No. Signal I/O Voltage Description
YC1 1 +3.3V1 I 3.3 V DC 3.3 V DC power to FRPWB-S
Connected to
the main front
PWB
2 +5V1 I 5 V DC 5 V DC power to FRPWB-S
3 +24V1 I 24 V DC 24 V DC power to FRPWB-S
4 EEP SCLK I 0/3.3 V DC (pulse) EEPROM clock signal
5 EEP SDA I/O 0/3.3 V DC (pulse) EEPROM data signal
6 FRONT OPEN O 0/3.3 V DC FCSW: On/Off
7 GND - - Ground
8 GND - - Ground
9 GND - - Ground
YC2 1 FRONTDLP1_FAN I 0/24 V DC DEVFM1: On/Off
Connected to
the engine
PWB
2 FRONTDLP2_FAN I 0/24 V DC DEVFM2: On/Off
3 WTNR_LED I 0/5 V DC (pulse) WTLED LED emitter signal
4 WTNER_CHECK O Analog WTS detection signal
5 WTNR_SET - - Not used
6 DLP_VCONT3 I Analog TS-Y control signal
7 TPD3 O Analog TS-Y detection signal
8 DRM3_POSITION O 0/3.3 V DC DPS-Y: On/Off
9 ERS3_DR I 24/0 V DC CL-Y: On/Off
10 DLP_VCONT2 I Analog TS-C control signal
11 TPD2 O Analog TS-C detection signal
12 DRM2_POSITION O 0/3.3 V DC DPS-C: On/Off
13 ERS2_DR I 24/0 V DC CL-C: On/Off
14 DLP_VCONT1 I Analog TS-M control signal
15 TPD1 O Analog TS-M detection signal
16 DRM1_POSITION O 0/3.3 V DC DPS-M: On/Off
17 ERS1_DR I 24/0 V DC CL-M: On/Off
YC3 1 ERASER Y O 24 V DC 24 V DC power to CL-Y
Connected to
the cleaning
lamp Y, drum
PWB Y and
drum position
sensor Y
2 ERS DR O 24/0 V DC CL-Y: On/Off
3 +3.3V1 O 3.3 V DC 3.3 V DC power to DRPWB-Y
4 EEP SCL O 0/3.3 V DC (pulse) DRPWB-Y EEPROM clock signal
5 EEPSDA I/O 0/3.3 V DC (pulse) DRPWB-Y EEPROM data signal
6 GND - - Ground
7 A0(GND) - - Ground
8 A1(OPEN) - - Not used
9 +5V1 O 5 V DC 5 V DC power to DPS-Y
10 POS SENS 3 I 0/3.3 V DC DPS-Y: On/Off
11 GND - - Ground
YC4 1 GND - - Ground
Connected to
the develop-
ing PWB Y
2 SDA I/O 0/3.3 V DC (pulse) DEVPWB-Y EEPROM data signal
3 SCK O 0/3.3 V DC (pulse) DEVPWB-Y EEPROM clock signal
4 +3.3V1 O 3.3 V DC 3.3 V DC power to DEVPWB-Y
5 TPD3 I Analog TS-Y detection signal
6 +24V1 O 24 V DC 24 V DC power to DEVPWB-Y
7 VCONT 3 O Analog TS-Y control signal
