Kyocera FS-C8500DN - Page 336

2KA
2-3-38
YC8 B15 FEED1 JAM O 0/3.3 V DC FSW1: On/Off
Connected to
the engine
PWB
B16 MPF2 JAM O 0/3.3 V DC MPPCSW: On/Off
B17 LSU SOL DR I 0/24 V DC LSUCSOL: On/Off
B18 REG JAM O 0/3.3 V DC RSW: On/Off
B19 FED1 CLT REM I 0/24 V DC PFCL1: On/Off
B20 MT_PD I 0/3.3 V DC PCM current control signal
YC9 1 ROL MT PD I 0/3.3 V DC MM current control signal
Connected to
the engine
PWB
2 ROL MT DR I 0/3.3 V DC MM: On/Off
3 ROL MT CLK I 0/3.3 V DC (pulse) MM clock signal
4 REG MT PD I 0/3.3 V DC RM current control signal
5 REG MT DR I 0/3.3 V DC RM: On/Off
6 REG MT CLK I 0/3.3 V DC (pulse) RM clock signal
YC10 1 GND - - Ground
Connected to
the registra-
tion switch,
MP paper
conveying
switch and
feed switch 1
2 REG JAM I 0/3.3 V DC RSW: On/Off
3 +5V1 O 5 V DC 5 V DC power to RSW
4 GND - - Ground
5 MPF2 JAM I 0/3.3 V DC MPPCSW: On/Off
6 +5V1 O 5 V DC 5 V DC power to MPPCSW
7 GND - - Ground
8 FEED1 JAM I 0/3.3 V DC FSW1: On/Off
9 +5V1 O 5 V DC 5 V DC power to FSW1
YC11 1 CAS OPEN I 0/3.3 V DC LC3SW: On/Off
Connected to
the left cover
3 switch and
feed switch 2
2 GND - - Ground
3 GND - - Ground
4 FEED2 JAM I 0/3.3 V DC FSW2: On/Off
5 +5V1 O 5 V DC 5 V DC power to FSW2
YC12 1 GND - - Ground
Connected to
the feed
switch 3
2 FEED3 JAM I 0/3.3 V DC FSW3: On/Off
3 +5V1 O 5 V DC 5 V DC power to FSW3
YC13
1 ROL UP2 CLT
REM
O 0/24 V DC FCL2: On/Off
Connected to
the feed
clutch 1/2
2 +24V2 O 24 V DC 24 V DC power to FCL2
3 REG UP1 CLT
REM
O 0/24 V DC FCL1: On/Off
4 +24V2 O 24 V DC 24 V DC power to FCL1
Connector Pin No. Signal I/O Voltage Description
