Kyocera FS-C8500DN - Page 337

2KA
2-3-39
YC14 A1 LOOP SENS I Analog LS: On/Off
Connected to
the loop sen-
sor, JAM LED
PWB 1/2,
loop fan
motor, left
cover 1
switch, duplex
switch and
duplex motor
A2 GND - - Ground
A3 +5V1 O 5 V DC 5 V DC power to LS
A4 GND - - Not used
A5 BELT JAM - - Not used
A6 +5V1 - - Not used
A7 GND - - Not used
A8 DU ENTER JAM - - Not used
A9 +5V1 - - Not used
A10 +5V1 O 5 V DC 5 V DC power to JLEDPWB2
A11 JAM2 LED O 0/5 V DC (pulse) LED emitter signal
A12 +5V1 O 5 V DC 5 V DC power to JLEDPWB1
A13 JAM1 LED O 0/5 V DC (pulse) LED emitter signal
A14 SENSOR FAN O 0/24 V DC LFM: On/Off
A15 +24V2 O 24 V DC 24 V DC power to LFM
B1 NC - - Not used
B2 NC - - Not used
B3 COV FAN1 REM - - Not used
B4 +24V2 - - Not used
B5 COV FAN2 REM - - Not used
B6 +24V2 - - Not used
B7 DU OPEN I 0/3.3 V DC LC1SW: On/Off
B8 GND - - Ground
B9 GND - - Ground
B10 DU JAM I 0/3.3 V DC DUSW: On/Off
B11 +5V1 O 5 V DC 5 V DC power to DUSW
B12 DU AN O 0/24 V DC (pulse) DUM drive control signal
B13 DU BN O 0/24 V DC (pulse) DUM drive control signal
B14 DU AP O 0/24 V DC (pulse) DUM drive control signal
B15 DU BP O 0/24 V DC (pulse) DUM drive control signal
YC15 1 LSU SOL DR O 0/24 V DC LSUCSOL: On/Off
Connected to
the LSU
cleaning sole-
noid
2 +24V2 O 24 V DC 24 V DC power to LSUCSOL
Connector Pin No. Signal I/O Voltage Description
