Kyocera FS-C8500DN Service Manual

1
B
C
D
A
E
F
H
G
Supplied parts
A Paper feeder..................................................1
B Pin .................................................................2
C Retainer......................................................... 1
D Paper size plate............................................. 2
E S Tite screw M4 × 10.....................................1
English
F Stopper R.......................................................1
G Stopper L........................................................1
H S Tite screw M4 × 20 ....................................4
Be sure to remove any tape and/or cushioning
material from supplied parts.
Precaution for unpacking
Hold the positions shown in the figure and
remove the paper feeder from the outer case.
Pièces fournies
A Bureau papier................................................ 1
B Broche ...........................................................2
C Élément de retenue .......................................1
D Plaque de format de papier ........................... 2
Français
E Vis S Tite M4 × 10..........................................1
F Butée R..........................................................1
G Butée L...........................................................1
H Vis S Tite M4 x 20 .........................................4
Veillez à retirer les morceaux de bande
adhésive et/ou les matériaux de rembourrage
des pièces fournies.
Précaution pour le déballage
Saisir les emplacements indiqués sur
l’illustration et retirer le bureau papier du boîtier
extérieur.
Partes suministradas
A Alimentador de papel.....................................1
B Clavija............................................................2
C Retén............................................................. 1
D Placa de tamaño de papel.............................2
Español
E Tornillo S Tite M4 × 10 ...................................1
F Tope R............................................................1
G Tope L ............................................................1
H Tornillos S Tite M4 x 20..................................4
Asegúrese de despegar todas las cintas y/o
material amortiguador de las partes
suministradas.
Precauciones para el desembalaje
Sujete por las posiciones indicadas en la figura
y desmonte el alimentador de papel de la caja
de embalaje.
Gelieferte Teile
A Papiereinzug ................................................. 1
B Stift ................................................................2
C Halterung.......................................................1
D Papierformatplatte .........................................2
Deutsch
E S-Tite-Schraube M4 × 10...............................1
F Anschlag R.....................................................1
G Anschlag L .....................................................1
H S-Tite-Schrauben M4 × 20 ............................4
Entfernen Sie Klebeband und/oder
Dämpfungsmaterial vollständig von den
mitgelieferten Teilen.
Vorsichtsmaßnahme beim Auspacken
Halten Sie den Papiereinzug an den in der
Abbildung gezeigten Stellen, und heben Sie ihn
aus dem äußeren Karton heraus.
Parti di fornitura
A Unità di alimentazione della carta..................1
B Perno.............................................................2
C Fermo ............................................................1
D Piastra formato carta .....................................2
Italiano
E Vite S Tite M4 × 10 ........................................1
F Fermo R.........................................................1
G Fermo L..........................................................1
H Vite S Tite M4 × 20 ........................................4
Accertarsi di rimuovere tutti i nastri adesivi e/o il
materiale di imbottitura dalle parti fornite.
Precauzioni per il disinballaggio
Mantenere le posizioni indicate nella figura e
rimuovere l’unità di alimentazione della carta
dall’involucro esterno.
同梱品
A ペーパーフィーダ .....................1
B ピン .................................2
C 取付板 ...............................1
D ペーパーサイズプレート ...............2
E ビス M4×10 S タイト ..................1
日本語
F 転倒防止金具 R .......................1
G 転倒防止金具 L .......................1
H ビス M4×20 S タイト .................4
同梱品に固定テープ、緩衝材が付いている場合
は必ず取り外すこと。
開梱時の注意
開梱時は、イラストの位置を持って外ケースか
ら取り出す。
附属品
A 供纸盒...............................1
B 固定插销.............................2
C 安装板...............................1
D 复印纸尺寸托板.......................2
简体中文
E 紧固型 S 螺丝 M4×10 ................. 1
F 限位器 R ............................. 1
G 限位器 L ............................. 1
H 紧固型 S 螺丝 M4×20 ................ 4
如果附属品上带有固定胶带、缓冲材料时务必揭
下。
开包时的注意事项
开包时，拿住图示的位置从外箱内取出。

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
