Kyocera FS-C8500DN Service Manual

2KA
1-3-25
U034 When [LSU Out Top B/W] is selected.
Large size: 218 mm or more in width of paper.
4. Press the Menu key.
5. Press the OK key to output a test pattern.
6. Press the Menu key.
7. Change the setting value using the Left/Right Select keys.
For output example 1, increase the value. For output example 2, decrease the value.
Figure 1-3-4
8. Press the OK key. The value is set.
Remark
When changing the setting value of [Large] each item is modified, equal to amount of the value which is
changed adds also the value of [Small] each item and is pulled.
Maintenance
item No.
Description
Display Description Setting
range
Default
setting
Change in
value per step
MPT (L) B/W Paper feed from MP tray
(when large size paper is used)
-3.0 to 3.0 0 0.1 mm
Cas (L) B/W Paper feed from cassette
(when large size paper is used)
-3.0 to 3.0 0 0.1 mm
Dup (L) B/W Duplex mode (second)
(when large size paper is used)
-3.0 to 3.0 0 0.1 mm
MPT (S) B/W Paper feed from MP tray
(when small size paper is used)
-3.0 to 3.0 0 0.1 mm
Cas (S) B/W Paper feed from cassette
(when small size paper is used)
-3.0 to 3.0 0 0.1 mm
Dup (S) B/W Duplex mode (second)
(when small size paper is used)
-3.0 to 3.0 0 0.1 mm
Correct image
Output
example 1
Output
example 2
Leading edge
registration
(20 ± 1.5 mm)

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
