Kyocera FS-C8500DN Service Manual

2KA-2
1-3-37
U100
Displaying: [Check DC1 Bias]
1. The current setting is diplayed.
Setting: [Adjust DC2 Bias]
1. Select the item to be set.
2. Change the value using the Left/Right Select keys.
Increasing the setting makes the image lighter; decreasing it makes the image darker.
3. Press the OK key. The value is set.
Setting: [Set L.Temp.(Drum)]
1. Change the value using the Left/Right Select keys.
2. Press the OK key. The value is set.
Setting: [Set Charger Freq.]
1. Select the item to be set.
2. Change the value using the Left/Right Select keys.
3. Press the OK key. The value is set.
Completion
Press the Back key. The screen for maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
(C) Full Main charger DC bias for cyan (full speed)
(M) Full Main charger DC bias for magenta (full speed)
(Y) Full Main charger DC bias for yellow (full speed)
(K) Full Main charger DC bias for black (full speed)
(C) Half Main charger DC bias for cyan (half speed)
(M) Half Main charger DC bias for magenta (half speed)
(Y) Half Main charger DC bias for yellow (half speed)
(K) Half Main charger DC bias for black (half speed)
(K) B/W Main charger DC bias for black in black/white mode
Display Description Setting range Initial setting
(C) Full Main charger DC bias for cyan (full speed) -128 to 127 0
(M) Full Main charger DC bias for magenta (full speed) -128 to 127 0
(Y) Full Main charger DC bias for yellow (full speed) -128 to 127 0
(K) Full Main charger DC bias for black (full speed) -128 to 127 0
(C) Half Main charger DC bias for cyan (half speed) -128 to 127 0
(M) Half Main charger DC bias for magenta (half speed) -128 to 127 0
(Y) Half Main charger DC bias for yellow (half speed) -128 to 127 0
(K) Half Main charger DC bias for black (half speed) -128 to 127 0
(K) B/W Main charger DC bias for black in black/white
mode
-128 to 127 0
Display Description Setting range Initial setting
Time Pre-charge time at power supply ON 0 to 6 1
Display Description Setting range Initial setting
Normal Main charger frequency 0 to 65535 31449
B/W Main charger frequency in black/white mode 0 to 65535 28544

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
