Kyocera FS-C8500DN Service Manual

2KA
1-3-38
U101
Setting the voltage for the primary transfer
Description
Sets the control voltage for the primary transfer.
Purpose
To change the setting when any density problems, such as too dark or light, occur.
Method
1. Press the OK key.
2. Select an item to be set.
3. Press the OK key. The screen for setting each item is displayed.
Setting: [Normal]
1. Select the item to be set.
2. Change the value using the Left/Right Select keys.
3. Press the OK key. The value is set.
Setting: [Add Color]
1. Select the item to be set.
2. Change the value using the Left/Right Select keys.
3. Press the OK key. The value is set.
Setting: [Surround Correct]
1. Select On or Off.
Initial setting: On
2. Press the OK key. The setting is set.
Completion
Press the Back key. The screen for maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
Normal Setting the primary transfer positive voltage for magenta
Add Color Setting the Addition value
Surround Correct Environmental correction ON/OFF setting
Display Description Setting range Initial setting
(M) Full Primary transfer positive voltage for magenta
(full speed)
0 to 255 116
(M) Half Primary transfer positive voltage for magenta
(half speed)
0 to 255 90
(M) Rev. B/W Primary transfer reverse voltage for magenta
in black/white mode
0 to 255 120
Display Description Setting range Initial setting
(C) Addition value (cyan) -127 to 127 5
(Y) Addition value (yellow) -127 to 127 5
(K) Addition value (black) -127 to 127 20
(C) 2nd Addition value for the second side (cyan) -127 to 127 0
(M) 2nd Addition value for the second side (magenta) -127 to 127 -5
(Y) 2nd Addition value for the second side (yellow) -127 to 127 -5
(K) 2nd Addition value for the second side (black) -127 to 127 -15
Display Description
Off Environmental correction is not performed
On Environmental correction is performed
