Kyocera FS-C8500DN Service Manual

2KA
1-3-42
U107
Setting the transfer cleaning voltage
Description
Sets the cleaning control voltage for transfer belt unit.
Purpose
Change settings if an offset has occurred due to the failure of cleaning the transfer belt.
Method
1. Press the OK key.
2. Select an item to be set.
3. Press the OK key. The screen for setting each item is displayed.
Setting: [Belt Clean A (F)]
1. Select an item to be set.
2. Change the value using the Left/Right Select keys.
3. Press the OK key. The value is set.
Setting: [Belt Clean A (H)]
1. Select an item to be set.
2. Change the value using the Left/Right Select keys.
3. Press the OK key. The value is set.
Setting: [Belt Clean A B/W]
1. Select an item to be set.
2. Change the value using the Left/Right Select keys.
3. Press the OK key. The value is set.
Maintenance
item No.
Description
Display Description
Belt Clean A (F) Transfer belt cleaning voltage (printing)
Belt Clean A (H) Transfer belt cleaning voltage (using thick paper)
Belt Clean A B/W Transfer belt cleaning voltage in black/white mode
Belt Clean B Transfer belt cleaning voltage (paper interval)
Display Description Setting range Initial setting
[W]<160 Small sizes (under 160 mm wide) 0 to 255 93
160<=[W]<220 Medium sizes (160 to under 220 mm
wide)
0 to 255 93
220<=[W] Large sizes (more than 220 mm wide) 0 to 255 93
Display Description Setting range Initial setting
[W]<160 Small sizes (under 160 mm wide) 0 to 255 62
160<=[W]<220 Medium sizes (160 to under 220 mm
wide)
0 to 255 62
220<=[W] Large sizes (more than 220 mm wide) 0 to 255 62
Display Description Setting range Initial setting
[W]<160 Small sizes (under 160 mm wide) 0 to 255 120
160<=[W]<220 Medium sizes (160 to under 220 mm
wide)
0 to 255 120
220<=[W] Large sizes (more than 220 mm wide) 0 to 255 120

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
