Kyocera FS-C8500DN Service Manual

2KA
1-3-57
U147
Setting for toner applying operation
Description
Sets the mode for removing charged toner in the developing unit (T7 control: Toner applying operation).
Purpose
Changing settings are not required. However, when the documents with lower print density (e.g. less than 2%)
should customarily printed in a great volume, mode must be changed.
If the charged toner stays inside the developing unit, density decreases.
Method
1. Press the OK key.
2. Select an item to be set.
3. Press the OK key. The screen for setting each item is displayed.
Setting: [Operation Mode]
1. Change the setting using the Left/Right Select keys.
Initial setting; M1
2. Press the OK key. The setting is set.
Setting: [Operation Value]
1. Select the item to be set.
2. Change the value using the Left/Right Select keys.
*: The initial setting value depends on the setting of [Drum Clean.].
3. Press the OK key. The value is set.
Maintenance
item No.
Description
Display Description
Operation Mode Mode settings for toner applying operation
Operation Value Detailed settings for toner applying operation
Display Description
Off Do not applying the toner operation
M1 Normal mode
M2 Toner consumption mode
Display Description
Setting
range
Initial
setting
Trans. Time Duration of toner applying 0 to 255 (s) 50
Upper Limit Upper limit printing ratio of toner applying quantity
with each mode
0 to 10 (%) 5.0
Sleeve Clean. Toner collection operational interval on developing
sleeve after the toner applying operation (T7 control)
10 to 300 (s) 60
Drum Clean. Settings for developing the toner layer in accor-
dance with coverage ratio
M1/M2 M1
Minimum
Value*
Toner layer width when [Set Drum Cleaning Mode] is
selected
0 to 30 (mm) M1: 10
M2: 20

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
