LACO PROTOCOL DESCRIPTIONS TITANTEST™
131
© 2018 LACO TECHNOLOGIES, INC. - TitanTest itra01en1-07 SB.fm - 1807
AutoTest result (command 702)
12.6 Group commands**
Group calibration history (command 275, one entry)

** Feature not available in TITANTEST™ Maintenance model
19 Delay timer
20 Helium BG limit
21 External trigger
22 Test timer
Value Meaning
0Idle
1Running 1
2Pass
3Fail
Meaning Data type Offset
Year UINT8 0
Month UINT8 1
Day UINT8 2
Hour UINT8 3
Minute UINT8 4
Second UINT8 5
Calibration mode UINT8 6
Filament UINT8 7
Measure mode UINT8 8
Mass UINT8 9
Anode voltage UINT16 10
Factor ULTRA FLOAT 12
Factor FINE FLOAT 16
Factor GROSS FLOAT 20
Calibrated leak [mbar*l/s] FLOAT 24
Ion current (leak opened) [A] FLOAT 28
Ion current (leak closed) [A] FLOAT 32
Value Meaning
