If there is a leak, it will be shown in the display and - depending on your set-
tings – also indicated by an acoustic signal.
6.5.3 Executing an Auto Test**
1. Connect any required accessories or equipment.
Remove the blank flange on the test port and establish the connection
with the test object or test system.
2. Check whether the parameters shown in the "Standby" window apply.
The device is ready if the display shows the "Standby" window after the
run-up of the device.

Ensure that TITANTEST™ is set to "Auto Test" operating mode.
3. In order to achieve the most precise possible measuring results, allow
the device to warm up for approx. 30 minutes (
see Chapter 6.1: "Switch-
ing on the device", page 21).
4. In order to start the measurement operation, press "START/STOP" on the
control unit.

The test object is evacuated and the pressure is displayed during the
pump-down operation.

Once the measuring pressure is reached, the measured value display ap-
pears (see Chapter 6.5.4).
TITANTEST™ automatically executes a stored test procedure.
5. Once the "Test timer" elapses, the test sequence ends automatically. By
pressing the "START/STOP" button, you can end the test sequence pre
-
maturely.
The display will then show the "Standby" window and the result of the
test.
6. Switch the test object.
7. Press the "START/STOP" button to start another Auto Test.
6.5.4 Measured value display
Once the measurement pressure is reached, the measured value display ap-
pears with the last used display type:
 Analog/digital with bar graph and large-format numbers or
 Graphically as a function of measuring time
** Feature not available in TITANTEST™ Maintenance model
Risk of injury from suction on test port flange
If the Auto Test function of the T
ITANTEST™ is activated, bodily parts blocking
the inlet flange may be sucked in.
► Always use an inlet filter.
► Keep parts of the body away from the inlet flange.
